2 - 17
2 Models and External Dimensions
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
2-4 External and Mounting Dimensions
2
2-4-1 Servo Drive Dimensions
z Wall Mounting
External dimensions Mounting dimensions
z Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
3-phase 400 VAC: R88D-KN06F-ECT-L/-KN10F-ECT-L/
-KN15F-ECT-L (600 W to 1.5 kW)
92
150
172
4
150 140
70
14.5
70
2-M4
92
92
60
40
10
Ø 5.2 Ø 5.2
170 180 150
5.2 5.2
10
40
R2.6
172
70
4
19.5
2.5
40
18
6
(94)*
170
(158)*
4-M4
Rectangular
hole
* Rectangular hole dimensions are reference values.
