Omron SYSMAC NX-CIF101 User Manual

7 Serial Communications
7 - 22
NX-series Communications Interface Units User’s Manual (W540)
 Output Notification Data
Input Data Length 0000 hex
Input Data 01 00 hex, 00 hex, 00 hex, 00 hex
NX object name Value
Output SID 03 hex
Input SID Response 04 hex
Output Data Type 0000 hex
Output Sub Info 0000 hex
Output Data Length 0000 hex
Output Data 01 00 hex, 00 hex, 00 hex, 00 hex
Step Process
CPU Unit or communications mas-
ter processing
Communi-
cations
di
rection
*1
CIF Unit processing
1 Receiv-
ing
123456
-- •
The CIF Unit receives 123456 from the
se
ri
al line.
• A parity error is detected.
2 • Input-
ting 12
• Discard-
ing 12
• The communications master
recei
ves the input notification data
given on the right.
• The communications master knows
that the
re is a parity error because
the Parity Error in the Port Status in
the input notification data is TRUE.
• The communications master dis-
cards 12.

• The CIF Unit inputs the following input noti-
fication data to pass 12 to the CPU Unit or
co
mmun
ications master.
• At the same time, the CIF Unit tells the CPU
U
n
it or communications master that there is
a parity error.
• The above input notification data is held
u
ntil the CPU Unit or communications mas-
ter sends output notification data in which
the
Inpu
t SID Response is 05 hex.
3 Input
response
for 12
The communications master outputs
the fol
lowing output notification data to
tell the CIF Unit that 12 was received
normally.

• The CIF Unit receives the output notification
da
ta given on the left.
• The CIF Unit knows that 12 was normally
rece
ived by the CPU Unit or communica-
tions master because the Input SID
R
e
sponse in the output notification data is
05 hex.
NX object name Value
12
Incremented.
There is a parity
error.
2 bytes
There is an
error in the
receive data.
1012 hex
05 hex
03 hex
9000 hex
0000 hex
0002 hex
31 hex,
32 hex,
00 hex,
00 hex
Input Data 01
Port Status
Input SID
Output SID
Response
Input Data Type
Input Sub Info
Input Data Length
03 hex
05 hex
0000 hex
0000 hex
0000 hex
00 hex,
00 hex,
00 hex,
00 hex
Set the Input
SID.
Output SID
Input SID
Response
Output Data
Type
Output Sub Info
Output Data
Length
Output Data 01
