Ratings and Performance
Reader/Writer
EtherNet/IP, PROFINET
* Oil resistance has been tested using a specific oil as defined in the OMRON test method.
Note: The 0.5 m cable with two M12 connectors is attached to the Reader/Writer. The cable cannot be removed.
Modbus TCP
*1 Oil resistance has been tested using a specific oil as defined in the OMRON test method.
*2 Provided only with the V680S-HMD66-ETN.
Item Model
V680S-HMD63-EIP
V680S-HMD63-PNT
V680S-HMD64-EIP
V680S-HMD64-PNT
V680S-HMD66-EIP
V680S-HMD66-PNT
Dimensions
50W × 50H × 30D
(excluding protruding parts and cables)
75W × 75H × 40D
(excluding protruding parts and cables)
120W × 120H × 40D
(excluding protruding parts and cables)
Power supply voltage 24 VDC (−15% to +10%)
Consumption current 0.2A max.
Ambient operating
temperature
−10 to +55
°C (with no icing)
Ambient operating
humidity
25% to 85% (with no condensation)
Ambient storage
temperature
−25 to 70
°C (with no icing)
Ambient storage humidity 25% to 85% (with no condensation)
Insulation resistance 20 MΩ min. (at 500 VDC) between cable terminals and case
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min between cable terminals and case
Vibration resistance
No abnormality after application of 10 to 500 Hz, 1.5-mm double amplitude, acceleration: 100 m/s
2
, 10
sweeps in each of 3 axis directions (up/down, left/right, and forward/backward) for 11 minutes each
Shock resistance No abnormality after application of 500 m/s
2
, 3 times each in 6 directions (Total: 18 times)
Degree of protection
IP67 (IEC 60529: 2001)
Oil resistance equivalent to IP67F (JIS C 0920: 2003, Appendix 1) *
Materials Case: PBT resin, Filled resin: Urethane resin
Mass Approx. 240g Approx. 390g Approx. 760g
Installation method
Reader/Writer: Two M4 screws
(Use a screw of 12 mm or more in length.)
Branch cable joint: One M4 screws
Four M4 screws (Use a screw of 12 mm or more in length.)
Host device
communications interface
Ethernet 10BASE-T/100BASE-TX
Host device
communications protocol
EtherNet/IP, PROFINET
Accessories Instruction Sheet, Description of Regulations and Standard, IP address label
Item Model
V680S-HMD63-ETN V680S-HMD64-ETN V680S-HMD66-ETN
Dimensions
50W × 50H × 30D
(excluding protruding parts)
75W × 75H × 40D
(excluding protruding parts)
120W × 120H × 40D
(excluding protruding parts)
Power supply voltage 24 VDC (−15% to +10%)
Consumption current 0.2A max.
Ambient operating
temperature
−10 to +55
°C (with no icing)
Ambient operating
humidity
25% to 85% (with no condensation)
Ambient storage
temperature
−25 to 70
°C (with no icing)
Ambient storage humidity 25% to 85% (with no condensation)
Insulation resistance 20 MΩ min. (at 500 VDC) between cable terminals and case
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min between cable terminals and case
Vibration resistance
No abnormality after application of 10 to 500 Hz, 1.5-mm double amplitude, acceleration: 100 m/s
2
, 10
sweeps in each of 3 axis directions (up/down, left/right, and forward/backward) for 11 minutes each
Shock resistance No abnormality after application of 500 m/s
2
, 3 times each in 6 directions (Total: 18 times)
Degree of protection
IP67 (IEC 60529: 2001)
Oil resistance equivalent to IP67F (JIS C 0920: 2003, Appendix 1) *1
Materials Case: PBT resin, Filled resin: Urethane resin
Mass Approx. 120g Approx. 270g Approx. 640g
Installation method
Two M4 screws
(Use a screw of 12 mm or more in length.)
Four M4 screws (Use a screw of 12 mm or more in length.)
Host device
communications interface
Ethernet 10BASE-T/100BASE-TX
Host device
communications protocol
MODBUS TCP
Accessories Instruction sheet, Description of Regulations and Standard, IP address label, Ferrite core *2
