Omron V680S - Page 17

V680S Series
17
RF Tag
V680S-series
RF Tag (2K-byte Memory)
*1 The number of accesses is the total number of reads and writes.
*2 Oil resistance has been tested using a specific oil as defined in the OMRON test method.
Note: For details, refer to the User’s Manual (Cat. No. Z339).
RF Tag (8K-byte Memory)
*1 The number of accesses is the total number of reads and writes.
*2 Oil resistance has been tested using a specific oil as defined in the OMRON test method.
Note: For details, refer to the User’s Manual (Cat. No. Z339).
Item Model
V680S-D2KF67 V680S-D2KF67M V680S-D2KF68 V680S-D2KF68M
Memory capacity 2,000 bytes (user area)
Memory type FRAM
Data Retention 10 years after writing (85 °C or less)
Memory life One trillion writes for each block (85 °C or less), Access frequency *1 : One trillion accesses
Ambient operating
temperature
−20 to 85 °C (with no icing)
Ambient storage
temperature
−40 to 125 °C (with no icing)
Ambient operating
humidity
35% to 85%
Degree of protection
IP68 (IEC 60529:2001), Oil resistance equivalent to IP67G (JIS C 0920:2003, Appendix 1) *2.
IPX9K (DIN 40 050)
Vibration resistance
No abnormality after application of 10 to 2,000 Hz, 1.5-mm double
amplitude, acceleration: 150 m/s
2
, 10 sweeps each in X, Y, and Z
directions for 15 minutes each
No abnormality after application of 10 to 500 Hz, 1.5-mm double
amplitude, acceleration: 100 m/s
2
, 10 sweeps each in X, Y, and Z
directions for 11 minutes each
Shock resistance No abnormality after application of 500 m/s
2
, 3 times each in X, Y, and Z directions (Total: 18 times)
Dimensions 40 × 40 × 5 mm (W × H × D) 86 × 54 × 10 mm (W × H × D)
Materials PPS resin
Weight Approx. 11.5 g Approx. 12 g Approx. 44 g Approx. 46 g
Metal countermeasures None Provided None Provided
Item Model
V680S-D8KF67 V680S-D8KF67M V680S-D8KF68 V680S-D8KF68M
Memory capacity 8,192 bytes (user area)
Memory type FRAM
Data Retention 10 years after writing (85 °C or less)
Memory life One trillion writes for each block (85 °C or less), Access frequency *1 : One trillion accesses
Ambient operating
temperature
−20 to 85 °C (with no icing)
Ambient storage
temperature
−40 to 125 °C (with no icing)
Ambient operating
humidity
35% to 85%
Degree of protection
IP68 (IEC 60529:2001), Oil resistance equivalent to IP67G (JIS C 0920:2003, Appendix 1) *2.
IPX9K (DIN 40 050)
Vibration resistance
No abnormality after application of 10 to 2,000 Hz, 1.5-mm double
amplitude, acceleration: 150 m/s
2
, 10 sweeps each in X, Y, and Z
directions for 15 minutes each
No abnormality after application of 10 to 500 Hz, 1.5-mm double
amplitude, acceleration: 100 m/s
2
, 10 sweeps each in X, Y, and Z
directions for 11 minutes each
Shock resistance No abnormality after application of 500 m/s
2
, 3 times each in X, Y, and Z directions (Total: 18 times)
Dimensions 40 × 40 × 5 mm (W × H × D) 86 × 54 × 10 mm (W × H × D)
Materials PPS resin
Weight Approx. 11.5 g Approx. 12 g Approx. 44 g Approx. 46 g
Metal countermeasures None Provided None Provided
