The second connects your laser power supply to the control s
ystem. Just
like the first
, if you have an identical one already set up, you can simply plug in your old scr
ew
terminal block directly. Otherwise, take care to install the wiring correctly
H: Connection for Active-High Devices
L: Connection for Active-Low Devices
P: Line to the Laser Trigger, Water & Other Systems (such as a door switch)
G: Ground Wire for the Control System, PWM Level Shifters, Potentiometers, etc.
IN: Input Power for PWM Level Shifters or Potentiometers
5V: 5V Connection for Digital Signals
In the event can be
In the event of a problem with the power supply or
connection, contact customer service
CONTACT US
Thank you for choosing our products! If you have any questions or comments,
contact us at help@cs-supportpro.com and we'll resolve your issue ASAP!
For a .pdf copy of the latest version of these instructions, use the appropriate
app on your smartphone to scan the QR code to the right.
