4
Step 1.Remove pre-fitted locking bolts
and locking nuts
S
tep 2.Pass the reclining lever
through the corresponding hole in the
right handrest and aim at the
corresponding hole in the seat plate
S
tep 3.Lock with the lock bolt and the
lock nut
Pay attention to the direction of reclining
lever.
H
G
W1
W2
D
R
locking bolt
The diƌĞĐƟon of the nut is behind
Don't ƟŐhten the four bolts before turning them up
Ōer installing the rocker, ƟŐŚƚen the four screws
shown above
Step 1. Install the angle iron on the
handrest first
Step 2. Install handrest on the seat
plate.
Fourth: Install the reclining lever
Third：Attach the left and right handrest
to the seat plate
