ON Semiconductor MC33067 - Maximum Ratings; Ordering Information

MC34067, MC33067
http://onsemi.com
2
MAXIMUM RATINGS
Rating Symbol Value Unit
Power Supply Voltage V
CC
20 V
Drive Output Current, Source or Sink (Note 1)
− Continuous
− Pulsed (0.5 ms), 25% Duty Cycle
I
O
0.3
1.5
A
Error Amplifier, Fault, One−Shot, Oscillator and Soft−Start Inputs V
in
− 1.0 to + 6.0 V
UVLO Adjust Input V
in(UVLO)
− 1.0 to V
CC
V
Power Dissipation and Thermal Characteristics
DW Suffix, Plastic Package, Case 751G
T
A
= 25°C
Thermal Resistance, Junction−to−Air
P Suffix, Plastic Package, Case 648
T
A
= 25°C
Thermal Resistance, Junction−to−Air
P
D
R
q
JA
P
D
R
q
JA
862
145
1.25
100
mW
°C/W
W
°C/W
Operating Junction Temperature T
J
+ 150 °C
Operating Ambient Temperature
MC34067
MC33067
T
A
0 to + 70
− 40 to + 85
°C
Storage Temperature T
stg
− 55 to + 150 °C
ESD Capability, HBM Model − 2.0 kV
ESD Capability, MM Model − 200 V
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.
ORDERING INFORMATION
Device Package Shipping
†
MC33067DWG SOIC−16W
(Pb−Free)
47 Units / Rail
MC33067DWR2G SOIC−16W
(Pb−Free)
1000 / Tape & Reel
MC33067PG PDIP−16
(Pb−Free)
25 Units / Rail
MC34067DWG SOIC−16W
(Pb−Free)
47 Units / Rail
MC34067DWR2G SOIC−16W
(Pb−Free)
1000 / Tape & Reel
MC34067PG PDIP−16
(Pb−Free)
25 Units / Rail
†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging
Specifications Brochure, BRD8011/D.
