Onan emerald plus series User Manual

7-4
BLK/GRN
WHT
GRN
L1
L0
GND
120V
GENSET
BLK
WHT
20A
30A
120V
2ND A/C
JUNCTION BOX
SCHEMATIC—UP TO JUNCTION BOX
FIGURE 7-2. CONNECTIONS—5.0-6.5 KW GENSET, 30 AMP SHORE POWER, 2ND AIR CONDITIONER
* This neutral conductor must have
an ampacity of at least 60 amps.
** Replace with a 30 amp circuit
breaker if rated 20 amps.
BLK/GRN
WHT
GRN
120V
GENSET
BLK
WHT
30A
30A**
TO VEHICLE AC DISTRIBUTION PANEL***
240V
120V
N
L1
L2
L1
N
L2
50 AMP SHORE POWER
120V
L1 N* L2 GND
120V
50 AMP 3-POLE TRANSFER SWITCH
WITH NEUTRAL RATED AT LEAST 60 AMP
***
JUNCTION BOX
FIGURE 7-3. SCHEMATIC—5.0-6.5 KW GENSET AND 50-AMP SHORE POWER

Onan emerald plus series Specifications

General

Frequency	60 Hz
Fuel Type	Gasoline
Voltage Output	120V
Starter Type	Electric
Warranty	2 years
Weight	180 - 220 lbs (depending on model)
