Dual Mode IntelliPlug AVC014
SECTION
Table of Contents
1
2
3 4 5
INSTALLATION CONFIGURATION for TV - Audio Visual Mode
Step 5 Connect your devices using a power distribution panel (not supplied) to the slave socket on the IntelliPlug.
For items that may require continuous power, such as, a Hard Disc recorder, Video recorder or DVD recorder
see page 14.
Sub Woofer Lamp
Games ConsoleAV Amplifier
