Installation
1. Place the SV-9320 DVB-T Indoor Antenna in the
stand (we suggest vertical installation).
2. Use the coaxial cable to connect your DVB-T
Receiver or Digital TV Set to the SV-9320 DVB-T
Indoor Antenna.
➤ Connect “IEC Male” or “F Male” end of coaxial
cable to “IEC Female” or “F Female” connector on
DVB-T Receiver or Digital TV Set.
➤ Connect “F-male” end of coaxial cable to the
F-Female connector on SV-9320 DVB-T Indoor
Antenna.
3. If your DVB-T receiver can supply the antenna with 5
VDC/40mA from the F connector, then please continue
with step 4. Otherwise:
Use the included AC Adaptor for powering the
SV-9320 DVB-T Indoor Antenna.
➤ Connect Adaptor plug to the DC input jack of the
SV-9320 DVB-T Indoor Antenna.
➤ Connect AC end to the AC Outlet.
4. Adjust the orientation of the SV-9320 DVB-T
Indoor Antenna for best performance.
DVB-T receiver or
Digital TV
Antenna stand
AC Adaptor
Coaxial Cable
”IEC””F”
