OneOdio FM1 User Manual

4
Specifications
Type
Condenser
Polar pattern
Cardioid
Sampling rate
44.1~48kHz / 16 bits
Frequency response
20Hz~20kHz
Sensitivity
-38dB ±2dB
Maximum SPL
110dB
Signal-to-noise ratio
≥80dB
Total harmonic distortion
≤0.5% (1kHz)
Monitor output type
3.5mm
Monitor output impedance
32Ω
Monitor output power
10mW
Operating voltage
DC 5V ±0.25V
Operating current
500mA
Product Description
1. Sampling rate up to 48kHz / 16 bits
2. Cardioid condenser microphone
3. Microphone gain control
4. Operation indicator lamp &
microphone mute button
5. 3.5mm headphone monitoring jack
6. Monitoring on/off switch button
7. Type-C port
8. Pop filter
9. 2m USB-C to USB-A audio cable

OneOdio FM1 Specifications

General

Brand	OneOdio
Model	FM1
Category	Microphone
Language	English
