Product Overview
1 Microphone connection
2 Power ON/OFF / Volume knob
3 Down ( ) button (Channel / Menu)
4 Up ( ) button (Channel / Menu)
5 35/5 (35/5) button
6 Triple watch (TW) button
7 Squelch (SQ) button
8 LC display
9 Menu (MENU) button
10 Call (C) button
11 UHF Antenna connection
12 Power input connection (13.8V DC)
13 External speaker socket
Controls and Indicators
2 4
5 6
7
98 10
3
1
11 12 13
Front View
Rear View
Controls and Indicators
2 4
5 6
7
98 10
3
1
11 12 13
Front View
Rear View
Front view
Rear view
