Assembly Kit
Firstly unpack all components and make sure that you have all necessary
parts. If you miss any parts, please contact our support team. Check the
list:
MOUNTING KIT FOR SCREEN:
Install the bracket only on a stationary surface that is not subject to
vibration or external influences. Failure to do so may damage the
screens and / or the surface itself.
M4x12 (x4)
M-A
M6x12 (x4)
M-B
D6 (x4)
M-C
C (x1)
F (x1)
G (x1)
H (x1)
4 mm (x1)
I
5 mm (x1)
J
M6x10 (x5)
D
A (x1)
B (x1)
Drill
Drill bit
Ø mm10 (3/8")
20 (7/8")Ø mm
E (x1)
2x
Required tools (not included):
To Next Page
