Onkyo C-S5VL Service Manual

1/27 PAGE
PARTS LIST C-S5VL
!: Safety part
s
N
OTE:
<B>: Black colo
r
<S>: Silver colo
r
<MUP>: European model
<MDC>: Canadian model
<MUR>: China model
<MUF>: Taiwanese model
EXPLODED VIEW PARTS LIST
REF.NO. PART NAME DESCRIPTION PART NO.
REMARKS
Q'TY
EXP V
A001 CHASSIS (AS) 27100541
Chassis(27100535)+Spacer(27
270513)
1
N
EXP V
A003 BOTTOM LEG -- 27175445A
<B>
4
EXP V
A003 BOTTOM LEG -- 27175446A
<S>
4
EXP V
A005 CUSHION . 28141774 4
EXP V
A007 SCREW 3TTB+8B(3BC) 838430088GR 4
EXP V
A009 HOLDER KGLS-6S 27190011 7
EXP V
A011 HOLDER (CLAMP) WS-1NS 27190541 2
EXP V
A015 HOLDER KGPS-6S 27191260 1
EXP V
A016 WIRE TIE BSK-1 260208 1
EXP V
A017 BRACKET (PW) 27131067 1
N
EXP V
A018 SPACER (HO) 27270525 2
EXP V
A019 SPACER T0.5*Φ8*Φ3.5 27270463 4
EXP V
A020 SCREW 3TTB+8B(3BC) 838430088GR CHASSIS-BRACKET(PW) 2
EXP V
A021 SCREW 3P+6FN(3BC) 82143006GR NGPS-BRACKET(PW) 2
EXP V
A027 LABEL (DVD3) 29364728 1
EXP V
A035 CUSHION (T3*W35*D10) 28141741 MP013:MECHA FFC 1
EXP V
A050 REAR PANEL C-S5VL MUP 27124050
<MUP>
1
N
EXP V
A050 REAR PANEL C-S5VL MDC 27124051
<MDC>
1
N
EXP V
A050 REAR PANEL C-S5VL MUR 27124052
<MUR>
1
N
EXP V
A050 REAR PANEL C-S5VL MUF 27124053
<MUF>
1
N
EXP V
A051 SCREW 3TTB+8B(3BC) 838430088GR REARPANEL 14
EXP V
A052 TAPE TAPE(CLOTH-8U) 29110082 REAR PANEL:0.02:MT 1
EXP V
A053 SCREW 4TTB+10B(3BC) 838440108GR AC INLET 2
EXP V
A101 F BRACKET (AS)(B) 27111549A <B> F Bracket+Standby Knob 1
N
EXP V
A101 F BRACKET (AS)(S) 27111550B
<S> F Bracket+Standby Knob
1
N
EXP V
A103 GUIDE (MECHA-L) 27268241 1
N
EXP V
A105 GUIDE (MECHA-R) 27268242 1
N
