Onkyo C-S5VL Service Manual

2/27 PAGE
EXP V
A107 SCREW 3P+6FN(3BC) 82143006GR 2
EXP V
A109 SCREW 3TTB+8B(3CM)SR 801637 2
EXP V
A110 SCREW 3TTB+8B(3BC) 838430088GR MP013:HP 1
EXP V
A111 SCREW 3TTB+8B(3CM)SR 801637 FBRA-PWB 11
EXP V
A112 SCREW 3TTB+8B(3CM)SR 801637 MP013:FBRA-CHASSIS 6
EXP V
A113 KNOB (POWER)AS(B) 28326787
<
B
>
N
o
b+K
no
b
b
ase
+St
an
b
y
knob
1
N
EXP V
A113 KNOB (POWER)AS(S) 28326788A
<
S
>
N
o
b+K
no
b
b
ase
+St
an
b
y
knob
1
N
EXP V
A115 IB CUSHION W15*3t TAPE 28141585 FL:0.01:MT 1
EXP V
A117 KNOB (HP)(B) 28326743
<B>
1
N
EXP V
A117 KNOB (HP)(S) 28326744A
<S>
1
N
EXP V
A119 DOOR (SACD)(B) 28148752
<B>
1
N
EXP V
A119 DOOR (SACD)(S) 28148753
<S>
1
N
EXP V
A121 CUSHION (BUTYL) 28141748 1
EXP V
A123 TAPE -- 29110161 FBRACKET 2
EXP V
A201 F PANEL (CS5VLB) 27213279
<B MUP>
1
N
EXP V
A201 F PANEL (CS5VLS) 27213280
<SMUP>
1
N
EXP V
A201 F PANEL (CS5VLB) 27213279
<BMDC>
1
N
EXP V
A201 F PANEL (CS5VLS) 27213280
<SMUR>
1
N
EXP V
A201 F PANEL (CS5VLS) 27213280
<SMUF>
1
N
EXP V
A203 FACET (S) 28198906 1
EXP V
A207 CLEAR PLT (DIS) 28192249
<B>
1
N
EXP V
A207 CLEAR PLT (S) 28192252A
<S>
1
N
EXP V
A209 SCREW 3TTB+8B(3BC) 838430088GR FPANEL 3
EXP V
A251 CLEAR PLT (RE)(B) 28192250
<B>
1
N
EXP V
A251 CLEAR PLT (RE)(S) 28192251
<S>
1
EXP V
A257 KNOB (SACD)(B)AS 28326739A
<B> Knob+Guide+Facet
1
N
EXP V
A257 KNOB (SACD)(S)AS 28326740A
<S> Knob+Guide+Facet
1
N
EXP V
A259 GUIDE (DIRECT)(B) 27268243
<B>
1
N
EXP V
A259 GUIDE (DIRECT)(S) 27268244
<S>
1
EXP V
A261 GUIDE (REJECT)(B) 27268239
<B>
1
N
EXP V
A261 GUIDE (REJECT)(S) 27268240
<S>
1
N
EXP V
A263 GUIDE (PLAY)(B) 27268235
<B>
1
N
EXP V
A263 GUIDE (PLAY)(S) 27268236
<S>
1
N
EXP V
A265 CUSHION -- 28141606 F BRACKET 2
EXP V
A267 CUSHION (M) 28141803 MECHA 2
N
EXP V
A401 COVER C-S5VL(B) 28210048Z
<B> Not bent
1
N
EXP V
A401 COVER C-S5VL(B) 28210048
<B> Bent
1
EXP V
A401 COVER C-S5VL(S) 28210049Z
<S> Not bent
1
N
EXP V
A401 COVER C-S5VL(S) 28210049
<S> Bent
1

Onkyo C-S5VL Specifications

General

Frequency range	4 - 50000 Hz
Audio formats supported	MP3, WMA
Total Harmonic Distortion (THD)	0.0025 %
Built-in speaker(s)	No
CD-RW playback	Yes
Device type	HiFi CD player
Product color	Silver
Disc loading type	Tray
Number of optical discs	1 discs
Volume control	Rotary
Headphone outputs	1
Power consumption (typical)	16 W
Package depth	448 mm
Package width	562 mm
Package height	212 mm
Package weight	7000 g

Weight and Dimensions

Depth	318 mm
Width	435 mm
Height	80 mm
Weight	4500 g
