Onkyo C-S5VL Service Manual

3/27 PAGE
EXP V
A402 SCREW 3TTB+8B(3BC) 838430088GR
<B> COVER
7
EXP V
A402 SCREW 3TTB+8B(3CM)SR 801637
<S> COVER
7
EXP V
A404 CUSHION -- 28141817A
EXP V
F001A LABEL 2A/125V 29362525
<MDC>
1
EXP V
F001B FUSE 2A-SE-EAK FUSE 252074GR
! <MUP>
1
EXP V
F001B FUSE 2A-SE-EAK FUSE 252074GR
! <MUR>
1
EXP V
F001B FUSE 2A-SE-EAK FUSE 252074GR
! <MUF>
1
EXP V
F001C FUSE 2A-UL/T-233 252320GR
! <MDC>
1
EXP V
P1002C FFC NCFCC-242012 204C242012 1
EXP V
P1203C FFC NCFC4-15057 204415057 1
N
EXP V
P1401C FFC NCFC4-17055 204417055 1
N
EXP V
P1703C FFC NCFC4-17056 204417056 1
N
EXP V
P1901C SOCKET AS NSAS-30P1341 20044193005UL 1
EXP V
U001 F/E, B/E circuit PC board a'ssy BADG-0266-1A 1H558566-1A All Destinations 1
N
EXP V
U002 Display circuit PC board a'ssy BADIS-0252-1A 1H558552-1A All Destinations 1
N
EXP V
U003 Audio terminal PC board a'ssy BAAF-0254-1A 1H558554-1A All Destinations 1
N
EXP V
U004 Connection PC board BAETC-0255-1A 1H558555-1A All Destinations 1
N
EXP V
U005 Power switch PC board a'ssy BASW-0256-1A 1H558556-1A All Destinations 1
N
EXP V
U006 Remote sensor PC board a'ssy BAETC-0257-1A 1H558557-1A All Destinations 1
N
EXP V
U007 Headphone terminal PC board a'ssy BAAF-0258-1A 1H558558-1A All Destinations 1
N
EXP V
U008 AC inlet terminal PC board BAPS-0259-1A 1H558559-1A All Destinations 1
N
EXP V
U010 Power supply unit NGPS-0099-100-240V 24150099 1
N
EXP V
Z101 DVD Mechanism TD-505SF-4 24801038 1
N
EXP V
Z102 SCREW 2TTB+8B(3CM) 838120088GR MECHA-PWB 2
EXP V
Z103 HOLDER (M) 27191335 2
N
EXP V
Z104 SCREW (M) 801652A HOLDER(M)-DVD M 4
N
EXP V
Z107 TAPE TAPE(CLOTH-16U) 29110083 DVD M:0.03:MT 1
PACKING PARTS LIST
C-S5VL
!: Safety parts
NOTE:
<B>: Black color
<S>: Silver color
<MUP>: European model
<MDC>: Canadian model
<MUR>: China model
<MUF>: Taiwanese model
REF.NO. PART NAME DESCRIPTION PART NO.
REMARKS
Q'TY
PKG
A201 PAD AS 29092474A 1
PKG
A202 SHEET -- 29095847 1

Onkyo C-S5VL Specifications

General

Frequency range	4 - 50000 Hz
Audio formats supported	MP3, WMA
Total Harmonic Distortion (THD)	0.0025 %
Built-in speaker(s)	No
CD-RW playback	Yes
Device type	HiFi CD player
Product color	Silver
Disc loading type	Tray
Number of optical discs	1 discs
Volume control	Rotary
Headphone outputs	1
Power consumption (typical)	16 W
Package depth	448 mm
Package width	562 mm
Package height	212 mm
Package weight	7000 g

Weight and Dimensions

Depth	318 mm
Width	435 mm
Height	80 mm
Weight	4500 g
