Onkyo C-S5VL

4/27 PAGE
PKG
A203 POLY BAG w250xd350 29100250A For Instruction Manual 1
PKG
A204 TAPE NITTO NO.29 29110149 1
PKG
A301 CARTON -- 29055019 1
N
PKG
A302A EAN LABEL -- 29390836B
<BMUP>
{ 1}
N
PKG
A302A EAN LABEL -- 29390837A
<SMUP>
{ 1}
N
PKG
A302A UPC LABEL -- 29390838
<BMDC>
{ 1}
N
PKG
A302A EAN LABEL -- 29390839
<SMUR>
{ 1}
N
PKG
A302A EAN LABEL -- 29390840
<SMUF>
{ 1}
N
PKG
A303 PP TAPE W50 SBT-70 29110200 :1.5:MT 1
PKG
A311 LABEL (CHINA)SACD 29390864 only <SMUR> 1
N
PKG
A901 INST SHEET WEEE 29355537A only <MUP> 1
PKG
A902 WRNTY CARD (ONKYO) 29365135 only <MDC> 1
PKG
A903 WRNTY CARD (ONKYO-CH) 29365098B only <MUR> 1
PKG
A911 INS MANUAL En(C-S5VL) 29400088A 1
N
PKG
A912 INS MANUAL U2FrEs(C-S5VL) 29400089A only <MUP><MDC> 1
N
PKG
A913 INS MANUAL U4ItDeNlSv(C-S5VL) 29400090A only <MUP> 1
N
PKG
A914 INS MANUAL Ct(C-S5VL) 29400091 only <MUF> 1
N
PKG
A915 INS MANUAL Cs(C-S5VL) 29400092 only <MUR> 1
N
A916 INST SHEET CHINA ROHS 29355616A only <MUR> 1
A917 INS MANUAL Ru (C-S5VL) 29400094 only <MUP> 1
N
PKG
E801 PIN CORD PIN-CORD 2010238 1
PKG
E802 BATTERY R6/AA(UM-3) 3010194 2
PKG
E802 or BATTERY R6/AA(UM-3) 3010054 ( 2)
PKG
E803 PLUG CORD 3.5-MINI PLUG (RI) 2010200 1
PKG
E805 REMO CON RC-749C 24140749 1
N
PKG
P901 AC CORD AS-CEE-3 253298VOL
! <MUP>
1
PKG
P901 AC CORD AS-UC-2 253352ATES
! <MDC>
1
PKG
P901 AC CORD AS-CCC 253358VOL
! <MUR>
1
PKG
P901 AC CORD AS-CNS 253432VOL
! <MUF>
1
PRINTED CIRCUIT BOARD PARTS LIST C-S5VL
U001 F/E, B/E circuit PC board a'ssy (BADG-0266-1A)
PCB
CIRCUIT N
O
PART NAME DESCRIPTION PART NO. REMARKS Q'TY
BADG0266
C1001 CHIP ELECT C CEWX4V-220M 3981G2217R2 1
BADG0266
C1002 CHIP ELECT C CEWX4V-47M 3981G4707R2 1
BADG0266
C1003 CHIP ELECT C CEWX4V-47M 3981G4707R2 1
BADG0266
C1004 C-CERA C CK725F1A-105Z1 332181050R1 1
BADG0266
C1005 C-CERA C CK725F1A-105Z1 332181050R1 1
