Onkyo CR-425UKD

62
Specifications
Specifications and features are subject to change without notice.
General
CR-525UKD CR-425UKD/CR-325UKD
Power Supply: AC 220 - 230 V, 50/60 Hz AC 220 - 230 V, 50/60 Hz
Power Consumption: 67 W 58 W
Stand-by Power Consumption: 0.25 W 0.25 W
Dimensions
(W × H × D):
205 × 116 × 367 mm 205 × 116 × 367 mm
Weight: 4.0 kg 4.0 kg
Audio Inputs
Analog Inputs: 2 (DOCK IN, MD/TAPE IN)
Audio Outputs
Analog Outputs: 1 (MD/TAPE OUT)
Subwoofer Pre Outputs: 1
Speaker Outputs: 2
Phones: 1
Amplifier Section
CR-525UKD CR-425UKD/CR-325UKD
Power Output: 26 W + 26 W (4Ω, 1 kHz, 10% THD)
2ch × 20 W (4Ω, 1 kHz, 2ch driven, IEC)
26 W + 26 W (4Ω, 1 kHz, 10% THD)
2ch × 20 W (4Ω, 1 kHz, 2ch driven, IEC)
THD (Total Harmonic
Distortion):
0.4% (1 kHz, 1 W) 0.4% (1 kHz, 1 W)
Damping Factor: 25 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance: 150 mV/50 kΩ (DOCK IN, MD/TAPE IN)
Output Level and Impedance: 150 mV/2.2Ω (MD/TAPE OUT)
Frequency Response: 10 Hz–100 kHz/±3 dB (DOCK, MD/TAPE)
Tone Control: ±6 dB, 80 Hz (BASS)
±8 dB, 10 kHz (TREBLE)
+7 dB, 80 Hz (S.BASS)
Signal to Noise Ratio: 100 dB (DOCK, MD/TAPE, IHF-A)
Speaker Impedance: 4 Ω–16 Ω
Tuner Section
CR-525UKD CR-425UKD/CR-325UKD
FM
Tuning Frequency Range: 87.5 MHz–108.0 MHz 87.5 MHz–108.0 MHz
AM
Tuning Frequency Range: 522 kHz–1611 kHz 522 kHz–1611 kHz
DAB
Tuning Frequency Range: 174.928–239.200 MHz 174.928–239.200 MHz
Frequency Response: 20 Hz–20 kHz 20 Hz–20 kHz
Signal to Noise Ratio: 94 dB 94 dB
THD (Total Harmonic Distortion): 0.09% 0.09%
CD
CR-525UKD CR-425UKD/CR-325UKD
Frequency Response: 4 Hz–20 kHz 10 Hz–20 kHz
Audio Dynamic Range: 96 dB 95 dB
THD (Total Harmonic
Distortion):
0.005% 0.009%
Wow and Flutter: Below threshold of measurability
