Specifications
Amplifier
Tuner
CD
USB
Speakers D-T05
General
■ Audio input
■ Video output
■ Audio output
■ Other
Specifications and features are subject to change without
notice.
Rated output power (IEC) 2ch
15 W (6 Ω, 1 kHz, 2ch driven)
THD + N (total harmonic distortion + N )
10 % (Power Rated)
0.5 % (1 kHz 1W)
Damping factor 60 (1 kHz, 8 Ω)
Input sensitivity and impedance
1000 mV/ 47 kΩ (LINE)
Frequency response 40 Hz–20 kHz/+0 dB, –3 dB
Tone control +10 dB, –10 dB ,100 Hz (BASS)
+10 dB, –10 dB, 10 kHz (TREBLE)
+4 dB/+8 dB, 80 Hz (S.BASS 1/2)
Signal to noise ratio 84 dB (LINE, IHF-A)
Speaker impedance 6–16 Ω
Tuning frequency range 87.50–108.00 MHz
Channel presets 30
Playable media CD and CD-R/CD-RW (music CDs
and MP3 CDs)
Playable media USB Flash Drive (MP3)
Type 2 way bass-reflex
Impedance 6 Ω
Maximum input power 30 W
Output sound pressure level 82 dB/W/m
Frequency response 55 Hz–50 kHz
Crossover frequency 4.5 kHz
Cabinet capacity 3.4 liter
Dimensions (W H D) 130 210 172 mm
(5-1/8" 8-1/4" 6-3/4")
(incl. grille and projection)
Weight 1.6 kg (3.5 lbs.)
Driver units 3-15/16" Cone Woofer
3/4" Balanced Dome Tweeter
Terminal Spring Type Color Coded
Other Magnetic shielding
Power supply AC 230 V, 50 Hz
Power consumption 30 W
Standby power consumption 0.2 W (when not charging iPod)
Dimensions (W H D) 215 100 270 mm
(8-1/2" 3-15/16" 10-5/8")
Weight 2.4 kg (5.3 lbs.)
Analog input LINE
Video output VIDEO OUT
Analog output HEADPHONES, SPEAKERS
USB 2.0 HS
