Onkyo DV-CP500 Service Manual

DV-CP500
SPECIFICATIONS
Specifications and features are subject to change without notice.
DVD Changer
Power supply AC 120 V, 60 Hz
Power consumption 20 W
Weight 15.4 lbs
External dimensions 17
1
/8" x 5
1
/16" x 16
15
/16" (W/H/D)
Signal system NTSC
Frequency range (digital audio) 48 kHz sampling 4 Hz to 22 kHz
96 kHz sampling 4 Hz to 42 kHz
Signal-to-noise ratio (digital audio) More than 90 dB
Audio dynamic range (digital audio) More than 95 dB
Harmonic distortion (digital audio) Less than 0.005 %
Wow and flutter Below measurable level
Operating conditions Temperature: 5 C to 35 C (41 F to 95 F), Operation status: Horizontal
Outputs
Video output 1.0 V (p-p), 75 ohm , ne gative sync., pin jack 1
S-video output (Y) 1.0 V (p-p), 75 ohm
, negative sync.
(C) 0.286 V (p-p), 75 ohm , Mini DIN 4-pin 1
Component video output (Y) 1.0 V (p-p), 75 ohm , negative sync., pin jack 1
(P
B)/(PR) 0.7 V (p-p), 75 ohm, pin jack 2
Audio output (digital output Optical) Optical connecter 1
Audio output (digital output Coaxial) 0.5 V (p-p), 75 ohm , pin jack 1
Audio output (analog output) 2.0 V (rms), 320 ohm , pin jack (L, R) 2
X
X
X
X
X
X
X
