Onkyo DV CP704 Service Manual

DV-CP704
EXPLODED VIEW
DV-CP704
3
2
5
6
4
1
M051
A216
A214
A215
x 8 pcs.
Q1101A
A033
A011
A001
A005
A004
A003
A013
A006
A002
A021
A018
A014
A008
A050
M014
M052
A030
M058
M057
M050
M062
M061
M001
M009
M010
M008
M007
M010
M006
M010
M005
A034
M015
A035
A053
M014
x 2 pcs.
A026
x 8 pcs.
A045
x 2 pcs.
A032
x 2 pcs.
A031
x 2 pcs.
A042
x 2 pcs.
A041
x 2 pcs.
A044
x 2 pcs.
A036
x 4 pcs.
A027
x 2 pcs.
A035
x 2 pcs.
Z004
x 2 pcs.
A055
A048
M012a
x 4 pcs.
M012b
x 4 pcs.
A051
x 2 pcs.
A054
x 12 pcs.
M056
x 2 pcs.
M060
x 4 pcs.
M014
x 4 pcs.
A026
x 3 pcs.
A022
x 2 pcs.
A016
x 2 pcs.
A017
x 2 pcs.
A019
x 10 pcs.
A019
x 4 pcs.
A025
x 2 pcs.
P1701
P1901
P1401
P1002
P7002
U002-1
U001
U002-4
U002-0
U002-5
U002-10
U002-11
U002-2
U002-3
U002-8
U002-6
U002-9
U003
F901
F902
M053
M002
M014
M012d
M012
M012e
M031
M012c
M030
A056
F102
F105
M011
x 3
M014
M013
Z001
A028
x 2 pcs.

Onkyo DV CP704 Specifications

Operating Environment

Operating temperature	5° to 35° C (41° F to 95° F)

Power

Power supply (U.S. model)	120 V AC, 60 Hz
Power supply (Australian model)	100–240 V AC, 50/60 Hz
Power consumption	13 W
Power consumption in Standby mode (U.S. model)	0.35 W
Power consumption in Standby mode (Australian model)	0.35 W

Audio Specifications

Signal-to-noise ratio	95 dB
Audio dynamic range	95 dB
Total harmonic distortion	0.007% (1 kHz)
Wow and flutter	Below threshold of measurability

Video Outputs

Component video Y	1.0 V (p–p), 75 Ω, negative sync, RCA/phono x3
Component video PB/PR	0.7 V (p–p), 75 Ω
S VIDEO Y	0.7 V (p–p), 75 Ω, negative sync, 4-pin mini DIN x1
S VIDEO C	0.286 V (p–p), 75 Ω
Composite video	1.0 V (p–p), 75 Ω, negative sync, RCA/phono x1

Audio Outputs

Optical output	–22.5 dBm, optical connector x1
Coaxial output	0.5 V (p–p), 75 Ω, RCA/phono x1
Analog output	2.0 V (rms), 540 Ω, RCA/phono x2
HDMI output	19 pin connector

Weight and Dimensions

Weight	5.5 kg (12.1 lbs.)
Dimensions (W x H x D)	435 X 91 X 432 mm (17-1/8 X 3-9/16 X 17 ins.)
