Onkyo DX-C390 Service Manual

U21 : STANDBY LED PC BOARD NASW-8055
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
SW-8055
D801 LED 225321 SLR-342VR
SW-8055
P801B PLUG 25055989 NPLG-3P941
SW-8055
R822 C-CARBON R 435033914R1 RN72K1J-391JE
SW-8055
R823 C-CARBON R 435034714R1 RN72K1J-471JE
SW-8055
R824 C-CARBON R 435038214R1 RN72K1J-821JE
SW-8055
R825 C-CARBON R 435031024R1 RN72K1J-102JE
SW-8055
S801 PUSH SW 25035718 NPS-111-S681
SW-8055
S802 PUSH SW 25035718 NPS-111-S681
SW-8055
S803 PUSH SW 25035718 NPS-111-S681
SW-8055
S804 PUSH SW 25035718 NPS-111-S681
SW-8055
S805 PUSH SW 25035718 NPS-111-S681
U22 : OUTPUT TERMINAL PC BOARD NAAR-8056
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
AR-8056
C165 C-CERA C 332161040R1 CK725F1E-104Z1
AR-8056
C166 C-CERA C 332161040R1 CK725F1E-104Z1
AR-8056
C167 C-CERA C 332161040R1 CK725F1E-104Z1
AR-8056
C168 ELECT C 394741007 CE04W16V10M(SC)
AR-8056
C174 CERA C 335321025 CK45B50V-102K
AR-8056
C301 VX C 393362207 CE04W35V-22M(VX)
AR-8056
C302 VX C 393362207 CE04W35V-22M(VX)
AR-8056
C303 TF C 374721024 ECQ-B50V-102J
AR-8056
C304 TF C 374721024 ECQ-B50V-102J
AR-8056
C305 TF C 374722724 ECQ-B50V-272J
AR-8056
C306 TF C 374722724 ECQ-B50V-272J
AR-8056
C307 TF C 374721824 ECQ-B50V-182J
AR-8056
C308 TF C 374721824 ECQ-B50V-182J
AR-8056
C309 VX C 393362207 CE04W35V-22M(VX)
AR-8056
C310 VX C 393362207 CE04W35V-22M(VX)
AR-8056
C311 ELECT C 394742217 CE04W16V220M(SC)
AR-8056
C312 ELECT C 394742217 CE04W16V220M(SC)
AR-8056
C315 C-CERA C 332161040R1 CK725F1E-104Z1
AR-8056
C904 ELECT C 394641037S CE04W16V10000M(VR)
AR-8056
C905 ELECT C 394642227S CE04W16V2200M(VR)
AR-8056
C906 ELECT C 394741007 CE04W16V10M(SC)
AR-8056
C908 ELECT C 394781017 CE04W50V100M(SC)
AR-8056
C909 C-CERA C 332152230R1 CK725F1H-223Z1
AR-8056
C910 ELECT C 394764707 CE04W35V47M(SC)
AR-8056
C911 ELECT C 394741007 CE04W16V10M(SC)
AR-8056
C913 ELECT C 394741007 CE04W16V10M(SC)
AR-8056
C915 ELECT C 394742217 CE04W16V220M(SC)
AR-8056
D301 ZENER D 224490470R2 UDZ4.7B
AR-8056
D901 DIODE 22380271F D3SBA20
AR-8056
D905 DIODE 22380260 RL1N4003
AR-8056
D905 or DIODE 22380035 GP104003E
AR-8056
D906 ZENER D 224553000R2 UDZS30B
AR-8056
D907 C-DIODE 223269R2 1SS355
AR-8056
D907 or C-DIODE 223234R2 1SS352
AR-8056
D908 C-DIODE 223269R2 1SS355
AR-8056
D908 or C-DIODE 223234R2 1SS352
AR-8056
D909 ZENER D 224550510R2 UDZS5.1B
AR-8056
E901 HOLDER 27190608-1 (CRAMP) UA-0 V0
AR-8056
L152 CHOKE COIL 230921R2 BLM21B222SPT
AR-8056
L153 CHOKE COIL 230921R2 BLM21B222SPT
AR-8056
L159 CHOKE COIL 230921R2 BLM21B222SPT
AR-8056
L901 CHOKE COIL 230921R2 BLM21B222SPT
AR-8056
P102B PLUG 25055147 NPLG-3P131
AR-8056
P103B PLUG 25055149 NPLG-5P133
AR-8056
P151 PIN JACK 25045628 NPJ-2PDRW435 <MDD>
AR-8056
P151 PIN JACK 25045628 NPJ-2PDRW435 <MPA,MPP>
AR-8056
P152 PIN JACK 25045548 NPJ-1PDOR369 <MDD>
AR-8056
P152 PIN JACK 25045548 NPJ-1PDOR369 <MPA,MPP>
AR-8056
P153 PIN JACK 25045589 NPJ-2PDB400
AR-8056
P705B PLUG 25055151 NPLG-7P135
57 of 63
