Onkyo DX-C390 Service Manual

DG-8057
R628 C-CARBON R 435030004R1 RN72K1J-000JE
DG-8057
S601 PUSH SW 25035716 NPS-111-S679
DG-8057
S602 PUSH SW 25035716 NPS-111-S679
DG-8057
S603 PUSH SW 25035716 NPS-111-S679
U24 : POWER TRANSFORMER PC BOARD NAPS-8058
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
PS-8058
C901 IS C
!
3300030 DE1307E472M-KH
PS-8058
C902 IS C
!
3300030 DE1307E472M-KH
PS-8058
C903 TF C 374723344 ECQ-V50V-334J
PS-8058
C912 TF C 374721044 ECQ-V50V-104J
PS-8058
C916 TF C 374723344 ECQ-V50V-334J
PS-8058
C917 TF C 374722244 ECQ-V50V-224J
PS-8058
P802B PLUG 25055988 NPLG-2P940
PS-8058
P901A PLUG 25055676 NPLG-2P632
PS-8058
P902A SOCKET AS 7012-6660-0 NSAS-12P1233
PS-8058
T902 CHOKE COIL 231287 NCH-3567
U25 : DISC SENSOR PC BOARD NAETC-8059
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
ETC-8059
C652 C-CERA C 332161040R1 CK725F1E-104Z1
ETC-8059
C653 C-CERA C 332152230R1 CK725F1H-223Z1
ETC-8059
C654 C-CERA C 332152230R1 CK725F1H-223Z1
ETC-8059
P702B SOCKET 25052239 NSCT-6P2136
ETC-8059
P702B or SOCKET 25052052 NSCT-6P1839
ETC-8059
P702B or SOCKET 25051850 NSCT-6P1637
ETC-8059
P703A SOCKET AS 2002E390415UL NSAS-4P1127
ETC-8059
Q651 PHT INT 24190046 GP2S28
ETC-8059
Q652 PHT CP 24120107 RPI-576
ETC-8059
R651 C-CARBON R 435031814R1 RN72K1J-181JE
ETC-8059
R652 C-CARBON R 435031544R1 RN72K1J-154JE
ETC-8059
R653 C-CARBON R 435033314R1 RN72K1J-331JE
ETC-8059
R654 C-CARBON R 435034744R1 RN72K1J-474JE
ETC-8059
R655 C-CARBON R 435030004R1 RN72K1J-000JE
ETC-8059
R656 C-CARBON R 435030004R1 RN72K1J-000JE
U26 : ROULETTE MOTOR PC BOARD NAETC-8060
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
ETC-8060
C655 C-CERA C 332161040R1 CK725F1E-104Z1
ETC-8060
P703B PLUG 25055440 NPLG-2P422
U27 : LOADING MOTOR PC BOARD NAETC-8061
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
ETC-8061
C656 C-CERA C 332161040R1 CK725F1E-104Z1
ETC-8061
P704A SOCKET AS 2002A340420UL NSAS-4P1138
U28 : CONNECTION PC BOARD NAETC-8062
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
ETC-8062
P752 SOCKET AS 7012-6748-0 NSAS-22P1253
ETC-8062
P751B PLUG 25055449 NPLG-11P431
U29 : ILLUMINATION PC BOARD NADIS-8066
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
DIS-8066
D802 LED 3700-2832-B SELU2L10C
DIS-8066
D802A HOLDER 27191190 (LED)LA-5-6
DIS-8066
D803 LED 3700-2832-B SELU2L10C
DIS-8066
D803A HOLDER 27191190 (LED)LA-5-6
DIS-8066
P802A SOCKET AS 7012-6665-0 NSAS-4P1232
DIS-8066
R820 C-CARBON R 435035604R1 RN72K1J-560JE
DIS-8066
R821 C-CARBON R 435035604R1 RN72K1J-560JE
U30 : POWER SWITCH PC BOARD NASW-8063 <MPP, MPA> ONLY
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
SW-8063
C907 IS C 3500196S RE275V-103M <MPP,MPA>
SW-8063
J901 CRIMP AS 2069943181UL CRIMP AS <MPP,MPA>
SW-8063
J902 CRIMP AS 2069943188UL CRIMP AS <MPP,MPA>
61 of 63
