Onkyo DX-C390 Service Manual

U23 : MECHANISM CONYROL PC BOARD NADG-8057
CIRCUIT NO. PART NAME PART NO. DESCRIPTION REMARK
DG-8057
C601 ELECT C 394841017 CE04W16V100M(SSK)
DG-8057
C602 C-CERA C 332152230R1 CK725F1H-223Z1
DG-8057
C605 C-CERA C 332161040R1 CK725F1E-104Z1
DG-8057
C606 ELECT C 394841017 CE04W16V100M(SSK)
DG-8057
C607 C-CERA C 332152230R1 CK725F1H-223Z1
DG-8057
C609 C-CERA C 332152230R1 CK725F1H-223Z1
DG-8057
C610 C-CERA C 332152230R1 CK725F1H-223Z1
DG-8057
C611 C-CERA C 332152230R1 CK725F1H-223Z1
DG-8057
D601 ZENER D 224490220R2 UDZ2.2B
DG-8057
D602 ZENER D 224490270R2 UDZ2.7B
DG-8057
D603 ZENER D 224550430R2 UDZS4.3B
DG-8057
D604 ZENER D 224550470R2 UDZS4.7B
DG-8057
P701B SOCKET 25052354 NSCT-17P2251
DG-8057
P701B or SOCKET 25052538 NSCT-17P2435
DG-8057
P702A SOCKET 25052202 NSCT-6P2099
DG-8057
P702A or SOCKET 25051813 NSCT-6P1600
DG-8057
P702A or SOCKET 25052015 NSCT-6P1802
DG-8057
P704B PLUG 25055988 NPLG-2P940
DG-8057
P705A SOCKET AS 7012-6663-0 NSAS-14P1239
DG-8057
P751A SOCKET AS 2002E242215UL NSAS-22P1126
DG-8057
Q601 IC 22240239 TA7291S
DG-8057
Q602 IC 22240239 TA7291S
DG-8057
Q603 TR 2216470R2 DTC114YKA
DG-8057
Q603 or TR 2216260R2 RN1407
DG-8057
Q603 or TR 2216340R2 KRC107S
DG-8057
Q604 TR 2216470R2 DTC114YKA
DG-8057
Q604 or TR 2216260R2 RN1407
DG-8057
Q604 or TR 2216340R2 KRC107S
DG-8057
Q605 TR 2216470R2 DTC114YKA
DG-8057
Q605 or TR 2216260R2 RN1407
DG-8057
Q605 or TR 2216340R2 KRC107S
DG-8057
Q606 TR 2216470R2 DTC114YKA
DG-8057
Q606 or TR 2216260R2 RN1407
DG-8057
Q606 or TR 2216340R2 KRC107S
DG-8057
Q607 TR 2216470R2 DTC114YKA
DG-8057
Q607 or TR 2216260R2 RN1407
DG-8057
Q607 or TR 2216340R2 KRC107S
DG-8057
Q608 TR 2214373R2 2SA1162-O
DG-8057
R601 C-CARBON R 435031044R1 RN72K1J-104JE
DG-8057
R602 C-CARBON R 435031044R1 RN72K1J-104JE
DG-8057
R603 C-CARBON R 435032224R1 RN72K1J-222JE
DG-8057
R604 NF CARBON R 415470474 R25J-4.7
DG-8057
R605 C-CARBON R 435031044R1 RN72K1J-104JE
DG-8057
R606 C-CARBON R 435031044R1 RN72K1J-104JE
DG-8057
R607 C-CARBON R 435030004R1 RN72K1J-000JE
DG-8057
R609 C-CARBON R 435032214R1 RN72K1J-221JE
DG-8057
R610 C-CARBON R 435032234R1 RN72K1J-223JE
DG-8057
R611 C-CARBON R 435035624R1 RN72K1J-562JE
DG-8057
R612 C-CARBON R 435031034R1 RN72K1J-103JE
DG-8057
R613 NF CARBON R 415470474 R25J-4.7
DG-8057
R614 C-CARBON R 435031034R1 RN72K1J-103JE
DG-8057
R615 C-CARBON R 435031034R1 RN72K1J-103JE
DG-8057
R616 C-CARBON R 435031034R1 RN72K1J-103JE
DG-8057
R617 C-CARBON R 435031034R1 RN72K1J-103JE
DG-8057
R618 C-CARBON R 435033324R1 RN72K1J-332JE
DG-8057
R619 C-CARBON R 435032744R1 RN72K1J-274JE
DG-8057
R620 C-CARBON R 435031054R1 RN72K1J-105JE
DG-8057
R621 C-CARBON R 435038224R1 RN72K1J-822JE
DG-8057
R622 C-CARBON R 435031034R1 RN72K1J-103JE
DG-8057
R623 C-CARBON R 435035624R1 RN72K1J-562JE
DG-8057
R624 C-CARBON R 435038224R1 RN72K1J-822JE
DG-8057
R625 C-CARBON R 435031054R1 RN72K1J-105JE
DG-8057
R626 C-CARBON R 435034724R1 RN72K1J-472JE
DG-8057
R627 C-CARBON R 435032224R1 RN72K1J-222JE
60 of 63
