Onkyo HT-S3910 User Manual

12
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Front Panel≫ Rear Panel≫ Remote≫
1. DIGITAL IN OPTICAL/COAXIAL jacks: Input TV or AV component digital audio
signals with a digital optical cable or digital coaxial cable.
2. HDMI OUT jacks: Transmit video signals and audio signals with an HDMI
cable connected to a TV.
3. HDMI IN jacks: Transmit video signals and audio signals with an HDMI cable
connected to an AV component.
4. POWER OUT port: You can also supply power (5 V/1 A) to the Streaming
media player connected to the HDMI IN terminal of this unit with a USB cable.
( p32) The playback function of music les and power supply to smart
phones/tablets, or other devices are not supported.
5. Power cord
6. TUNER AM/FM terminal: Connect the supplied antennas.
7. AUDIO IN jacks: Input TV or AV component audio signals with an analog audio
cable.
8. ZONE B LINE OUT jacks: Output audio signals with an analog audio cable
connected to a pre-main amplier in a separate room (ZONE B).
9. SUBWOOFER PRE OUT jacks: Connect a powered subwoofer sold
separately with a subwoofer cable. Up to two powered subwoofers can be
connected. The same signal is output from each SUBWOOFER PRE OUT
jack.
10. SPEAKERS terminals: Connect included speakers and subwoofer with
speaker cables. (FRONT L/R terminals of North American models support
banana plugs.)

Onkyo HT-S3910 Specifications

General

Disc types supported	No
Optical disc player type	Not included
3D	Yes
Video formats supported	-
Audio decoders	DTS:X, Dolby Atmos
RMS rated power	155 W
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	109 dB
Total Harmonic Distortion (THD)	10 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Front speaker type	2-way
Front speaker impedance	6 Ω
Front speakers RMS power	150 W
Front speaker frequency range	80 - 20000 Hz
Front speaker woofer diameter (imperial)	3 \
Satellite speaker frequency range	80 - 2000 Hz
Subwoofer frequency range	28 - 5000 Hz
Subwoofer driver diameter (imperial)	6.3 \
Product color	Black
HDMI in	4
SCART ports quantity	0
Number of HDMI outputs	1
Package depth	435 mm
Package width	535 mm
Package height	675 mm
Package weight	19000 g
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	445 W

Weight and Dimensions

Subwoofer weight	4600 g
Center speaker weight	600 g
Subwoofer dimensions (WxDxH)	230 x 331 x 389 mm
Front speaker dimensions (WxDxH)	98.5 x 106 x 140.5 mm
Center speaker dimensions (WxDxH)	244 x 102 x 96 mm
