General Specications
 Amplier Section
Rated Output Power (FTC) (North American)
With 8 ohm loads, both channels driven, from 20-20,000 Hz; rated 80 watts
per channel minimum RMS power, with no more than 0.08% total harmonic
distortion from 250 milliwatts to rated output.
With 8 ohm loads, both channels driven, from 100 Hz; rated 80 watts per
channel minimum RMS power, with no more than 0.08% total harmonic
distortion from 250 milliwatts to rated output. (SUBWOOFER)
Rated Output Power (IEC) (European, Australian and Asian)
5 ch × 135 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD
1 ch × 100 W at 6 ohms, 100 Hz, 1 ch driven of 1% THD (SUBWOOFER)
Maximum Effective Output Power (North American)
155 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
125 W at 6 ohms, 100 Hz, 1 ch driven of 10% THD (SUBWOOFER)
Maximum Effective Output Power (IEC)
5 ch × 155 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD (European)
1 ch × 125 W at 6 ohms, 100 Hz, 1 ch driven of 10% THD (European)
(SUBWOOFER)
Maximum Effective Output Power (JEITA)
5 ch × 155 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD (Australian, Asian
and Taiwanese)
1 ch × 125 W at 6 ohms, 100 Hz, 1 ch driven of 10% THD (Australian, Asian
and Taiwanese) (SUBWOOFER)
Dynamic Power (*)
* IEC60268-Short-term maximum output power
160 W (3 Ω, Front)
125 W (4 Ω, Front)
85 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20,000 Hz, half power)
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE (RCA))
Rated RCA Output Level and Impedance
1 V/470 Ω (SUBWOOFER PRE OUT)
1 V/2.3 kΩ (ZONE B LINE OUT)
Tone Control Characteristics
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio
109 dB (IHF-A, LINE IN, SP OUT)
Speaker Impedance
4 Ω - 16 Ω
Headphone Rated Output
80 mW + 80 mW (32 Ω, 1 kHz, 10% THD)
Supported impedance of Headphones
8 Ω - 600 Ω
Headphones Frequency Response
10 Hz - 100 kHz
 Tuner Section
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz (North American and Taiwanese)
87.5 MHz - 108.0 MHz, RDS (Others)
50 dB quieting sensitivity (FM MONO)
1.0 μV, 11.2 dBf (IHF, 1 kHz, 100% MOD)
AM Tuning Frequency Range
530 kHz - 1710 kHz (North American and Taiwanese)
522/530 kHz - 1611/1710 kHz (Others)
Preset Channel
40
 BLUETOOTH Section
Communication system
BLUETOOTH Specication version 4.2
Frequency band
2.4 GHz band
Modulation method
FHSS (Freq Hopping Spread Spectrum)

Onkyo HT-S3910 Specifications

General

Disc types supported	No
Optical disc player type	Not included
3D	Yes
Video formats supported	-
Audio decoders	DTS:X, Dolby Atmos
RMS rated power	155 W
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	109 dB
Total Harmonic Distortion (THD)	10 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Front speaker type	2-way
Front speaker impedance	6 Ω
Front speakers RMS power	150 W
Front speaker frequency range	80 - 20000 Hz
Front speaker woofer diameter (imperial)	3 \
Satellite speaker frequency range	80 - 2000 Hz
Subwoofer frequency range	28 - 5000 Hz
Subwoofer driver diameter (imperial)	6.3 \
Product color	Black
HDMI in	4
SCART ports quantity	0
Number of HDMI outputs	1
Package depth	435 mm
Package width	535 mm
Package height	675 mm
Package weight	19000 g
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	445 W

Weight and Dimensions

Subwoofer weight	4600 g
Center speaker weight	600 g
Subwoofer dimensions (WxDxH)	230 x 331 x 389 mm
Front speaker dimensions (WxDxH)	98.5 x 106 x 140.5 mm
Center speaker dimensions (WxDxH)	244 x 102 x 96 mm
