HTP-750X
EXPLODED VIEWS PARTS LIS
T
<Notes>
<L> : Lch
<R> : Rch
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED
SKW-750X (B) : POWERED SUBWOOFER
EXPLODED
AMPLIFIER SECTION (SKW-750X)
EXPLODED
Q515 TR 2SC5359-R 1 2203082
!
EXPLODED
Q515 or TR 2SC5359-O (1) 2203083
!
EXPLODED
Q516 TR 2SA1987-R(Q) 1 2203072
!
EXPLODED
Q516 or TR 2SA1987-O (1) 2203073GR
!
EXPLODED
Q541 TR 2SC3423-Y 1 2202104
EXPLODED
Q541 or TR 2SC3423-O (1) 2202103
EXPLODED
<Note>
EXPLODED
When replacement the following the transistor, made from the same HFE rank as the original type.
EXPLODED
Q515, Q516, Q541
EXPLODED
A01 HEAT SINK 230 1 27160591
EXPLODED
A02 CUSHION --- 2 28141682
EXPLODED
A03 CUSHION --- 1 28141691
EXPLODED
A05 SCREW 3TTB+8B(3BC) 8 838430088GR
EXPLODED
A06 TAPE TAPE(CLOTH-16U) (1) 29110083
EXPLODED
A07 ISO SHEET AC262 2 223025
EXPLODED
A08 SCREW 3SMS8W.SW+14B(CU) 2 801634
EXPLODED
A11 RETAINER (PCB) 1 27142025
EXPLODED
A101 REAR PANEL (MDD/MDC) 1 27123963A
EXPLODED
A102 BUSHING S-RELIEF #2271 1 27300750
!
EXPLODED
A103 KNOB (VOL) 1 28326463
EXPLODED
A104 SCREW 3SMS8W.SW+14B(3BC) 2 801433GR
EXPLODED
F901 FUSE 5A-UL/T-233 1 252326GR
!
EXPLODED
P901 AC CORD AS-UC-2 1 253333VOL
!
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
