Onkyo HTP-750 User Manual

2/12 PAGE
EXPLODED
P901 or AC CORD AS-UC-2 (1) 253368BLTK
!
EXPLODED
P901 or AC CORD AS-UC-2 (1) 253368AYUN
!
EXPLODED
P901 or AC CORD AS-UC-2 (1) 253368HSN
!
EXPLODED
T901 P TRANS NPT-1578D 1 2301948
!
EXPLODED
E801 WIRE TIE BSK-1 1 260208
EXPLODED
U01 MAIN PC BOARD ASS'Y NAAF-8829-1S* 1 1B138529-1S
EXPLODED
U03
POWER TRANS. PC BOARD ASS'Y
NAPS-8831-1S* 1 1B138531-1S
EXPLODED
U06 HOLDER PC BOARD NAETC-8834 1 --- NSP
EXPLODED
SPEAKER SECTION (SKW-750X)
EXPLODED
SP01a SPK SYSTEM ASS'Y(ALL) SKW-750X (B) MDD 1 000-SKW750XBMDD
EXPLODED
SP01b SUBWOOFER ASS'Y SKW-750X (B) MDD 1 000-SKW750XBESER
EXPLODED
<Note>
EXPLODED
SP01a = ALL
EXPLODED
SP01b = Without AMP unit, Speaker unit and Power transformer
EXPLODED
SP02 FOOT (PLASTIC) 4 D249-W55001B-01
EXPLODED
SP04 WOOD SCREW 4STB + 45A(BC) (FOR FOOT) 4 411-BE4045AB1
EXPLODED
SP06 WOOFER 10" (25cm) 4 ohm 80W (ONKYO ELE) 1 W2301G
