3/12 PAGE
EXPLODED
SP07 WOOD SCREW 4STB + 25A(BC) (FOR SP UNIT) 6 411-BE4025AB1
EXPLODED
SP08 LED HARNESS ASS'Y --- 1 335-SKW750-01
EXPLODED
SP11 WOOD SCREW 4STB + 16A(BC) (FOR AMP) 10 411-BE4016AB1
EXPLODED
SP12 SCREW 4 x 25 ED BLK (FOR P-TRANS) 4 412-DE40250B1
EXPLODED
SP13 CUSHION RUBBER PAD 19 x 89 T2 RUBBER (FOR P-TRANS) 2 442-902138-00
EXPLODED
SKF-750XF (B) <L> / <R> : FRONT SPEAKERS
EXPLODED
SP21 COMPLETE UNIT "SKF-750XF (B) <L>" 1 000-SKF750XFLB <L>
EXPLODED
SP22 SPEC LABEL (L) --- 1 600-750XFL-00 <L>
EXPLODED
SP23 COMPLETE UNIT "SKF-750XF (B) <R>" 1 000-SKF750XFRB <R>
EXPLODED
SP24 SPEC LABEL (R) --- 1 600-750XFR-00 <R>
EXPLODED
SKC-750XC (B) : CENTER SPEAKER
EXPLODED
SP31 COMPLETE UNIT "SKC-750XC (B)" 1 000-SKC750XCB
EXPLODED
SP32 SPEC LABEL --- 1 600-750X0C-00
EXPLODED
SKM-750XS (B) <L> / <R> : SURROUND SPEAKERS
EXPLODED
SP41 COMPLETE UNIT "SKM-750XS (B) <L>" 1 000-SKM750XSLB <L>
EXPLODED
SP42 SPEC LABEL (L) --- 1 600-750XML-00 <L>
EXPLODED
SP43 COMPLETE UNIT "SKM-750XS (B) <R>" 1 000-SKM750XSRB <R>
EXPLODED
SP44 SPEC LABEL (R) --- 1 600-750XMR-00 <R>
EXPLODED
SKB-750X (B) <L> / <R> : SURROUND BACK SPEAKERS
EXPLODED
SP51 COMPLETE UNIT "SKB-750X (B) <L>" 1 000-SKB750XBLB <L>
EXPLODED
SP52 SPEC LABEL (L) --- 1 600-750XBL-00 <L>
EXPLODED
SP53 COMPLETE UNIT "SKB-750X (B) <R>" 1 000-SKB750XBRB <R>
EXPLODED
SP54 SPEC LABEL (R) --- 1 600-750XBR-00 <R>
EXPLODED
SATELLITE PACKAGE
EXPLODED
--- SATELLITE PACKAGE SKF/SKC/SKM/SKB 1 000-HTP750XBMDDSER
EXPLODED
AS-140 (B) : SPEAKER STAND
EXPLODED
ST61a PIPE ASS'Y L LEFT 1 000-PLAS140CB
EXPLODED
PIPE + BRACKET + WIRE PIPE LEFT(WHITE/BLK) + SCREW + MIRAMAT BAG + OPP TAPE
EXPLODED
ST61b PIPE ASS'Y R RIGHT 1 000-PRAS140CB
EXPLODED
PIPE + BRACKET + WIRE PIPE RIGHT(RED/BLK) + SCREW + MIRAMAT BAG + OPP TAPE
EXPLODED
ST63 BASE STAND COVER --- 2 D215-S14001B-31
EXPLODED
ST64 BASE PLATE ASS'Y (With MODEL LABEL) 2 428-600001-10
EXPLODED
ST65 MODEL LABEL --- 2 600-0AS140-00
EXPLODED
ST66 LEG CUSHION --- 8 441-904107-00
