73
Universal P
or
t Option UP-A1 Dock f
or iP
od
—Continued
Status messa
ges
❏
PORT Reading
The A
V controller is checking the connection with the
dock.
❏
PORT Not Support
The A
V controller do not support the connected dock.
❏
PORT UP-A1
UP-A1 Dock is connected.
Notes:
•
The A
V controller displays the message “UP-A1” for
sev
eral seconds after recognizing the UP-A1.
•
When the status message is
not displayed on the A
V
controller’
s
display
, check the connection to your
iPod.
72
74
