SKW-100
Ref. No. Part No Description
1 BPR0018C001 Pote tube
2 DPP9630-158 Paper duct
3 EVM056C001 Wood box
4 Logo
5 IVE0037-001 Sponge
6 FSWA080-312 SPK drive
7 H011109-316 Screw
8 BPE0007C001 Foot
9 H011708-325 Screw
10 EVB0001C001 Wood board
11 H011708-370 Screw
12 BPC0021-001 Rear cove
13 APE0222C001 VR/LED ass'
14 APE0199CC23 Jack ass'
15 DLH0014-002 LED holde
16 GSE0117C001 PCB BKT
17 DSS0007-002 Washer
18 H121003-310 Screw
19 APE0199CD13 PCB ass'
20 H121009-308 Screw
21 IVE0183C001 Sponge
22 IVE0182C001 Sponge
23 GSP0047C001 Rear plate
24 H121009-312 Screw
25 BPK5018-003 Volume knob
26 47455-D65 Line cord
27 IVP0001-003 Polybag
28 DBU3050-110 Bushing
29 H110504-325 Screw
30 ICU0007-001 Rubber pad
31 TT11201C012 PWR trans
32 HWF8040-010 Washer FIB
33 H110303-308 Screw
34 GSE0110-001 Bracke
35 GSE0206-001 PCB bracke
36 HWT8540-110 Washer
37 HNM4070-130 Nu
38 H110303-314 Screw
39 GSE0093-002 PCB bracke
40 GAL0044C002 Heat sin
2210746 2SC945
RHI4558-001 JRC4558D
RHI0324-001 LM324N (14 PIN)
RHI7293-001 TDA7293 (15 PIN)
41 Sound absorber
SKW-100 Parts list
