HA12167FB/HA12169FB
13
Electrical Characteristics (Ta = 25°C, V
CC
= 14 V, Dolby Level 300 mVrms at
RECOUT) (Cont)
Test Conditions
—————————————————————————————————————
Specification REC
——————– REC RV Input Tape Input EQ Bias fin OUT
Item Symbol Min Typ Max Unit /PB /PV MPX NR B/C Pin Meter Speed Tape DAC DAC DAC [Hz] Level
——————————————————————————————————————————————————————————————————–
Level meter offset LMofs 1 — 150 300 mV REC RV ON OFF B RPI NOR NOR NOR 63 0 0 — — No signal
————————– ———————————————————————————————————————————–
LMofs 2 — 200 350 REC RV ON OFF B RPI 20 dB NOR NOR 63 0 0 — — No signal
———————————————————————————————————————————————————————————
DAC output Max V
B
Max 11.0 12.0 13.0 V REC RV OFF OFF B VRI1 NOR NOR MET 63 0 63 — —
———————————————————————————————————————————————————————————
DAC output Min V
B
Min — 0.5 1.0 V REC RV OFF OFF B VRI1 NOR NOR MET 63 0 0 — —
——————————————————————————————————————————————————————————————————–
Note: 1. HA12167: V
CC
= 12 V
HA12169: V
CC
= 11 V
2. V
CC
= 15 V
3. Adjust the input volume to Dolby level.
4. V
CC
= 15 V
Application Terminal
—————————
Input Output
———– ———–
R L R L Note
——1150
——1150
— — 29 32
— — 29 32
