HA12167FB/HA12169FB
69
Equalizer Gain vs. DAC Step
V
CC
= 14 V
0102030
DAC Step
31
26
21
16
EQ. Gain (dB)
EQin EQOUTout
f = 1 kHz
Vin = –26dBs
Equalizer Noise vs. DAC Step
V
CC
= 14 V
0102030
DAC Step
–60
–65
–70
–75
EQ. Noise (dBs)
JIS-A filter
