Onkyo TX-RZ800

20/60 PAGE
R6311 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
R6312 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
R6313 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
R6314 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
R6315 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
R6316 NON-FLAMMABLE CARBON FILM RESISTOR R25J-10 1 415471004T
1
R9301 CHIP TYPE CARBON RESISTOR RN72K1J-010JE 1 435030104R1
1
R9302 CHIP TYPE CARBON RESISTOR RN72K1J-272JE 1 435032724R1
1
R9303 CHIP TYPE CARBON RESISTOR RN72K1J-333JE 1 435033334R1
1
R9304 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R9305 CHIP TYPE CARBON RESISTOR RN72K1J-272JE 1 435032724R1
1
R9306 METAL RESISTOR RNU1/2WCJ-8.2 1 453530824T
[SW TRM]
P1008A SOCKET IMSA-9142S-24A 1 25053234
P4591B SOCKET IMSA-9142S-26A 1 25053235
P5010A SOCKET NSCT-3P2183 1 25052286
P5011A SOCKET NSCT-3P2183 1 25052286
P5012A SOCKET NSCT-3P2183 1 25052286
P5013A SOCKET NSCT-3P2183 1 25052286
P5014A SOCKET NSCT-3P2183 1 25052286
P5015A SOCKET NSCT-3P2183 1 25052286
P5016A SOCKET NSCT-3P2183 1 25052286
1
P5020A TERMINAL NTM-1P233(M1969) 1 25060302
1
P5021A TERMINAL NTM-1P233(M1969) 1 25060302
1
P5022A TERMINAL NTM-1P233(M1969) 1 25060302
1
P5023A TERMINAL NTM-1P233(M1969) 1 25060302
1
P5024A TERMINAL NTM-1P233(M1969) 1 25060302
1
P5025A TERMINAL NTM-1P233(M1969) 1 25060302
1
P5026A TERMINAL NTM-1P233(M1969) 1 25060302
P6030B SOCKET IMSA-9115S-09L 1 25052989
P6031B SOCKET IMSA-9115S-09L 1 25052989
P6032B SOCKET IMSA-9115S-09L 1 25052989
P6033B SOCKET IMSA-9115S-09L 1 25052989
P6034B SOCKET IMSA-9115S-09L 1 25052989
P6035B SOCKET IMSA-9115S-09L 1 25052989
P6036B SOCKET IMSA-9115S-09L 1 25052989
P9301 PLUG NPLG-5P119 1 25055135
P9302B PLUG NPLG-5P133 1 25055149
P9303B PLUG NPLG-9P137 1 25055153
U004 BAASP-1797-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D2901 DIODE D5SBA60 1 22380070
1
D2901A HEAT SINK RAD-083 1 27160271
1
D2901B SCREW 3P+6FN(3BC) 1 82143006GR
1
D2902 DIODE RB050M-30GTR 1 22380373R2
1
D2903 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2903 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2904 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2904 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2905 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D2905 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D2906 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2906 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2907 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D2907 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D2908 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2908 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2912 DIODE RB050M-30GTR 1 22380373R2
1
D2951 CHIP TYPE DIODE S1NB60-4062 1 22380318R2
1
D2953 DIODE RL1N4003 1 22380260T
1
D4231 ZENER DIODE DZ2J075M0L 1 224760750R2
1
D4231 or ZENER DIODE UDZS7.5B ( 1) 224550750R2
1
D4232 ZENER DIODE DZ2J075M0L 1 224760750R2
1
D4232 or ZENER DIODE UDZS7.5B ( 1) 224550750R2
1
D4693 CHIP TYPE DIODE DA2J10100 1 223303R2
