Onkyo TX-RZ800

29/60 PAGE
U005 BADG-1800-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D1200 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1200 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D1201 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1201 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D1202 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1202 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D1203 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1203 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D1204 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1204 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D1205 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1205 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D1206 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1206 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D1207 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D1207 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
Q1000 HYBRID IC TC74HCU04AF 1 222740046R2TO
1
Q1100 HYBRID IC S-13A1A33-U5T1U3 1 22242844R2
1
Q1200 HYBRID IC PCM9211PTR 1 22242703R2
1
Q1201 HYBRID IC PCM9211PTR 1 22242703R2
1
Q1202 HYBRID IC TC7SZU04FU 1 22242512R2TO
1
Q1301 HYBRID IC AK4458VN 1 22242927R2
1
Q1400 HYBRID IC NE5532APSR 1 22242283R2
1
Q1401 HYBRID IC NJM4580CG 1 22242922R2
1
Q1402 HYBRID IC NJM4580CG 1 22242922R2
1
Q1403 HYBRID IC NJM4580CG 1 22242922R2
1
Q1410 HYBRID IC NE5532APSR 1 22242283R2
1
Q1420 HYBRID IC NE5532APSR 1 22242283R2
1
Q1430 HYBRID IC NE5532APSR 1 22242283R2
1
Q1440 HYBRID IC NE5532APSR 1 22242283R2
[TRANS COIL]
1
L1000 EMI SUPPRESSION FILTER BK1608HS102-T 1 230955R2
1
L1001 EMI SUPPRESSION FILTER BK1608HS102-T 1 230955R2
1
L1003 CHOKE COIL LBC2518T470M 1 231364M470R2
1
L1201 CHOKE COIL LBC2518T4R7M 1 231364M047R2
1
L1202 CHOKE COIL LBC2518T4R7M 1 231364M047R2
1
L1203 CORE MMZ1608Y601BT 1 2350004R1
1
L1204 CORE MMZ1608Y601BT 1 2350004R1
1
L1205 CORE MMZ1608Y601BT 1 2350004R1
1
L1206 CORE BLM18PG181SN1D 1 2350005R1
1
L1207 CORE MMZ1608Y601BT 1 2350004R1
1
L1208 CHOKE COIL LBC2518T4R7M 1 231364M047R2
1
L1209 CHOKE COIL LBC2518T4R7M 1 231364M047R2
1
L1210 CORE MMZ1608Y601BT 1 2350004R1
1
L1211 CORE BLM18PG181SN1D 1 2350005R1
1
L1212 CORE BLM18PG181SN1D 1 2350005R1
1
L1301 CHOKE COIL LBC2518T4R7M 1 231364M047R2
1
L1302 CHOKE COIL LBC2518T4R7M 1 231364M047R2
1
X1201 CRYSTAL HC-49S 9C22.5792M 1 3010535R2
[CAPACITOR]
1
C1002 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1
1
C1003 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1
1
C1006 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1
1
C1007 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1
1
C1008 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1
1
C1010 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-080D1 1 342100802R1
1
C1011 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-080D1 1 342100802R1
1
C1012 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1
C1013 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W10V-220M(UTSP) 1 397532217AT
1
C1100 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 1 332071065R2
1
C1101 CHIP TYPE CERAMIC CAPACITOR CK732B16V-106K 1 332071065R2
C1200 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W10V-220M(UTSP) 1 397532217AT
1
C1201 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1
C1202 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W10V-220M(UTSP) 1 397532217AT
