Onkyo TX-RZ800

38/60 PAGE
1
S7634 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7634 or PUSH SWITCH NPS-111-S677 ( 1) 25035714T
1
S7635 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7635 or PUSH SWITCH NPS-111-S677 ( 1) 25035714T
U007 BAPRC-1802-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D3402 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D3402 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7001 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7001 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7002 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7002 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7003 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7003 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7004 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7006 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7006 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7009 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7009 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7012 DIODE RB050M-30GTR 1 22380373R2
1
D7013 DIODE RB050M-30GTR 1 22380373R2
1
D8003 ESD
IMSA-6802-01Y901_1608SIZE
1 4000255AR1
1
D8301 ZENER DIODE DZ2J036M0L 1 224760360R2
1
D8301 or ZENER DIODE UDZS3.6B ( 1) 224550360R2
1
D8400 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8400 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8900 DIODE CUS357 1 223320R2
1
D8901 DIODE CUS357 1 223320R2
1
D8902 DIODE CUS357 1 223320R2
1
D8907 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8907 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8909 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8909 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8942 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8942 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8943 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8943 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8963 DIODE RB050M-30GTR 1 22380373R2
1
Q1900 HYBRID IC PCM5101APWR 1 22242855R2
1
Q1901 HYBRID IC 74VHC4040FT 1 22274040E1R2TO
1
Q1902 HYBRID IC TC7WH241FU(TE12L_F) 1 22242076R2TO
1
Q1903 HYBRID IC PCM5101APWR 1 22242855R2
1
Q1904 HYBRID IC S-1333A33-M5T1U3 1 22242934R2
1
Q3001 HYBRID IC D830K013DZKB400 1 22242851R3
1
Q3002 HYBRID IC TC58DVM92A5TA10B3H 1 222W0125R3 firmware
1
Q3003 HYBRID IC A3V56S40GTP-60RX 1 22242891R2
1
Q3004 HYBRID IC A3V56S40GTP-60RX 1 22242891R2
1
Q3005 HYBRID IC TC7W32FU 1 22241162R2
1
Q3006 HYBRID IC PST803C270NM 1 22242894R2
1
Q3100 TRANSISTOR KRA302E 1 2218360R2 N
1
Q3100 or TRANSISTOR RN2102 ( 1) 2218270R2
1
Q3102 TRANSISTOR KRC402E 1 2218330R2 N
1
Q3102 or TRANSISTOR RN1102 ( 1) 2218230R2
1
Q3103 HYBRID IC S-1333A18-M5T1U3 1 22242956R2
1
Q3105 HYBRID IC MFI337S3959 1 22242820R2
1
Q3108 HYBRID IC KSZ8081RNBCA 1 22242921R2
1
Q3109 HYBRID IC S-13A1A12-U5T1U3 1 22242841R2
1
Q3120 HYBRID IC FP6861C-B1AS5CT 1 22242840R2
1
Q3121 HYBRID IC FP6861C-B1AS5CT 1 22242840R2
1
Q3200 HYBRID IC 74VHC541FT 1 22274541E1R2TO
1
Q3201 TRANSISTOR KRC402E 1 2218330R2 N
1
Q3201 or TRANSISTOR RN1102 ( 1) 2218230R2
1
Q3202 HYBRID IC 74LCX125FT 1 22274125BR2TO
1
Q3203 TRANSISTOR KRC402E 1 2218330R2 N
1
Q3203 or TRANSISTOR RN1102 ( 1) 2218230R2
