Onkyo TX-RZ800

59/60 PAGE
1
R8946 CHIP TYPE CARBON RESISTOR RN72K1J-103FE 1 435031032R1
1
R8949 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 1 435031044R1
1
R8952 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R8953 CHIP TYPE CARBON RESISTOR RN72K1J-682JE 1 435036824R1
1
R8954 CHIP TYPE CARBON RESISTOR RN72K1J-333FE 1 435033332R1
1
R8955 CHIP TYPE CARBON RESISTOR RN72K1J-124FE 1 435031242R1
1
R8956 CHIP TYPE CARBON RESISTOR RN72K1J-103FE 1 435031032R1
1
R8958 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R8959 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R8962 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R8963 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R8964 CHIP TYPE CARBON RESISTOR RN72K1J-563FE 1 435035632R1
1
R8965 CHIP TYPE CARBON RESISTOR RN72K1J-274JE 1 435032744R1
1
R8966 CHIP TYPE CARBON RESISTOR RN72K1J-103FE 1 435031032R1
1
R8968 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R8969 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R8970 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R8971 CHIP TYPE CARBON RESISTOR RN72K1J-472JE 1 435034724R1
1
R8972 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
1
R8976 CHIP TYPE CARBON RESISTOR RN72K1J-105JE 1 435031054R1
1
R8982 CHIP TYPE CARBON RESISTOR RN72K1J-104JE 1 435031044R1
1
R8983 CHIP TYPE CARBON RESISTOR RN72K1J-473JE 1 435034734R1
[SW TRM]
1
P2200B PLUG NPLG-7P920 1 25055967R2
1
P2201B SOCKET 40FMN-SMT-A-TF 1 25052857R2
1
P3100 SOCKET UJA01SB4090-72R 1 25053533R2
1
P3102A PLUG NPLG-5P918 1 25055965R2
1
P3103 SOCKET NSCT-9P2472 1 25052575R2
1
P3104 SOCKET 29-01000PH53-1 1 25053526R3
1
P7000B SOCKET IMSA-9618S-11A 1 25053336R2
1
P7001A SOCKET IMSA-9618S-13A 1 25053338R2
1
P7002A SOCKET NSCT-27P2490 1 25052593R2
1
P8001 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8001 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8001 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8002A PLUG(B to B) IMSA-9850B-24Y 1 25056207R2
1
P8003A PLUG(B to B) IMSA-9850B-24Y 1 25056207R2
1
P8021 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8021 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8021 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8601 SOCKET TCX3281-110187 1 25053520R3
1
P8611 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8611 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8611 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8621 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8621 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8621 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8631 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8631 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8631 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8641 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8641 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8641 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8651 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8651 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8651 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8661 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8661 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8661 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8671 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8671 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8671 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
RL8400 RELAY NRL-2P1A-DC4.5V-203 1 25065721R2
U008 BAHDM-1825-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
