2/60 PAGE
F9002 FUSE 12A-TUL-250V 1 252301GR !
F9002 or FUSE 12A-UL/T-314 ( 1) 252196GR !
P061 FAN ME92251V1-000U-A99 1 24502337
P061 or FAN D09A-12PG13 ( 1) 24502328
P062 FAN ME92251V1-000U-A99 1 24502337
P062 or FAN D09A-12PG13 ( 1) 24502328
P2101 FLEXIBLE FLAT CABLE NCFC5-401012 1 2045401012UL
P2203 FLEXIBLE FLAT CABLE NCFC5-151012 1 2045151012
P2204 FLEXIBLE FLAT CABLE NCFC7-070512 1 2047070512
P4605 FLEXIBLE FLAT CABLE NCFC7-091012 1 2047091012
P7000 FLEXIBLE FLAT CABLE NCFC5-111512 1 2045111512
P7001 FLEXIBLE FLAT CABLE NCFC5-131012 1 2045131012
P7002 FLEXIBLE FLAT CABLE NCFC5-274022 1 2045274022
P7591 FLEXIBLE FLAT CABLE NCFC5-150512 1 2045150512
P8691 CORD ASSEMBLY HDMI 0.65M 1 2010502A
P900 AC INLET R301X2PSn 1 25053358 !
[MECHANISM]
A1409 INSTRUCTION SHEET 15AVR_DTSX_U12 1 29355946
[TUNER UNIT]
U001 PARENT PC BOARD AS BAAMP-1779-1A * (Parent) 1 1B304579-1A MDC
POWER AMP(FINAL) PC BOARD AS BAAMP-1779-1A (Child) 1 1B3045779-1A-C
BAPS-1780 POWER SUPPLY(RELAY) PC BOARD AS BAPS-1780-1A (Child) 1 1B3045780-1A-C
BAPS-1781 POWER SUPPLY(PRI) PC BOARD AS BAPS-1781-1A (Child) 1 1B3045781-1A-C
CONNENCTOR(VD-ASP) PC BOARD AS BAETC-1782-1A (Child) 1 1B3045782-1A-C
THERMAL SENSOR PC BOARD AS BAETC-1783-1A (Child) 1 1B3045783-1A-C
U002 PARENT PC BOARD AS BAAF-1785-1H * (Parent) 1 1B304585-1H MDC
BAAF-1785 AMP/ ASP PC BOARD AS BAAF-1785-1H (Child) 1 1B3045785-1H-C
U003 PARENT PC BOARD AS BACLA-1787-1A * (Parent) 1 1B304587-1A MDC
AMP(VOLTAGE DRIVER L) PC BOARD AS BACLA-1787-1A (Child) 1 1B3045787-1A-C
AMP(VOLTAGE DRIVER R) PC BOARD AS BACLA-1788-1A (Child) 1 1B3045788-1A-C
AMP(VOLTAGE DRIVER C) PC BOARD AS BACLA-1789-1A (Child) 1 1B3045789-1A-C
AMP(VOLTAGE DRIVER SL) PC BOARD AS BACLA-1790-1A (Child) 1 1B3045790-1A-C
AMP(VOLTAGE DRIVER SR) PC BOARD AS BACLA-1791-1A (Child) 1 1B3045791-1A-C
AMP(VOLTAGE DRIVER SBL) PC BOARD AS BACLA-1792-1A (Child) 1 1B3045792-1A-C
AMP(VOLTAGE DRIVER SBR) PC BOARD AS BACLA-1793-1A (Child) 1 1B3045793-1A-C
BAPS-1794 POWER SUPPLY(FL) PC BOARD AS BAPS-1794-1A (Child) 1 1B3045794-1A-C
CONNECTOR(DG-ETC) PC BOARD AS BAETC-1795-1A (Child) 1 1B3045795-1A-C
U004 PARENT PC BOARD AS BAASP-1797-1A * (Parent) 1 1B304597-1A MDC
AUDIO PC BOARD AS BAASP-1797-1A (Child) 1 1B3045797-1A-C
BAVD-1798 VIDEO PC BOARD AS BAVD-1798-1A (Child) 1 1B3045798-1A-C
U005 PARENT PC BOARD AS BADG-1800-1A * (Parent) 1 1B304500-1A MDC
BADG-1800 DIGITAL(DIR/ DAC) PC BOARD AS BADG-1800-1A (Child) 1 1B3045800-1A-C
U006 PARENT PC BOARD AS BADIS-1810-1A * (Parent) 1 1B304510-1A MDC
BADIS-1810 DISPLAY PC BOARD AS BADIS-1810-1A (Child) 1 1B3045810-1A-C
BASW-1811 SWITCH/ LED PC BOARD AS BASW-1811-1A (Child) 1 1B3045811-1A-C
BASW-1812 SWITCH PC BOARD AS BASW-1812-1A (Child) 1 1B3045812-1A-C
VOLUME PC BOARD AS BAETC-1813-1A (Child) 1 1B3045813-1A-C
MIC PC BOARD AS BAETC-1814-1A (Child) 1 1B3045814-1A-C
PHONE JACK PC BOARD AS BAETC-1828-1A (Child) 1 1B3045828-1A-C
BARF-1829 TUNER PC BOARD AS BARF-1829-1A (Child) 1 1B3045829-1A-C
HOLDER(ETC-1828) PC BOARD AS BAETC-1830-1A (Child) 1 1B3045830-1A-C
U007 PARENT PC BOARD AS BAPRC-1802-1A * (Parent) 1 1B304502-1A MDC
PROCESSOR PC BOARD AS BAPRC-1802-1A (Child) 1 1B3045802-1A-C
U008 PARENT PC BOARD AS BAHDM-1825-1A * (Parent) 1 1B304525-1A MDC
TERMINAL(FRONT HDMI) PC BOARD AS BAHDM-1825-1A (Child) 1 1B3045825-1A-C
BARF-1826 Wi-Fi/BT CONECTOR PC BOARD AS BARF-1826-1A (Child) 1 1B3045826-1A-C
U012 WIFI BT COMB MODULE WCBN4601L-O1(wANT_OUT) 1 24850702
U012 = U012A + U012B + U012C + U012D(2pcs)
U012A ASSEMBLED PWB WCBN4601L-O1 1 24150122
U012B WIFI BT ANTENA AN-241NIPK06_L 1 2050093
U012C WIFI BT ANTENA AN-241NIPK06_R 1 2050094
U012D HOLDER HOLDER(ANT) 2 27191377
