Onkyo TX-RZ800

5/60 PAGE
1
Q6004 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q6005 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q6006 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q6090 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6091 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6092 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6093 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6094 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6095 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6096 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6902 TRANSISTOR 2SC2712-GR 1 2213145R2
Q6980 HYBRID IC LM61CIZ 1 22242212
1
Q6980A RETAINER (PTH) 1 27141884-1
Q9001 HYBRID IC STR-A6051M 1 222154
Q9003 HYBRID IC EL816MX 1 22242845
Q9003 or HYBRID IC PC123X8YFZ0F ( 1) 22242771
1
Q9004 HYBRID IC KIA431A-AT/P 1 22242770T
1
Q9005 TRANSISTOR KRC102S 1 2216190R2
1
Q9005 or TRANSISTOR RN1402 ( 1) 2214470R2
1
Q9006 TRANSISTOR 2SC2712-GR 1 2213145R2
1
Q9032 TRANSISTOR KRC102S 1 2216190R2
1
Q9032 or TRANSISTOR RN1402 ( 1) 2214470R2
1
Q9033 TRANSISTOR KRA102S 1 2216220R2
1
Q9033 or TRANSISTOR RN2402 ( 1) 2214530R2
[TRANS COIL]
L6800 SPEAKER OUTPUT FILTER COIL SC-0.8X5.5X18.5T 1 231431S
L6800 or SPEAKER OUTPUT FILTER COIL SC2-0.8X5.5X18.5T ( 1) 231455S
L6801 SPEAKER OUTPUT FILTER COIL SC-0.8X5.5X18.5T 1 231431S
L6801 or SPEAKER OUTPUT FILTER COIL SC2-0.8X5.5X18.5T ( 1) 231455S
L6802 SPEAKER OUTPUT FILTER COIL SC-0.8X5.5X18.5T 1 231431S
L6802 or SPEAKER OUTPUT FILTER COIL SC2-0.8X5.5X18.5T ( 1) 231455S
L6803 SPEAKER OUTPUT FILTER COIL SC-0.8X5.5X18.5T 1 231431S
L6803 or SPEAKER OUTPUT FILTER COIL SC2-0.8X5.5X18.5T ( 1) 231455S
L6804 SPEAKER OUTPUT FILTER COIL SC-0.8X5.5X18.5T 1 231431S
L6804 or SPEAKER OUTPUT FILTER COIL SC2-0.8X5.5X18.5T ( 1) 231455S
L6805 SPEAKER OUTPUT FILTER COIL SC-0.8X5.5X18.5T 1 231431S
L6805 or SPEAKER OUTPUT FILTER COIL SC2-0.8X5.5X18.5T ( 1) 231455S
L6806 SPEAKER OUTPUT FILTER COIL SC-0.8X5.5X18.5T 1 231431S
L6806 or SPEAKER OUTPUT FILTER COIL SC2-0.8X5.5X18.5T ( 1) 231455S
L9001 CHOKE COIL EM-UT2014-0033 1 231474
L9002 CHOKE COIL RCR1010NP-100M 1 231449M100
1
L9004 CORE BLM18PG181SN1D 1 2350005R1
1
L9005 CORE BLM18PG181SN1D 1 2350005R1
T9001 POWER TRANSFORMER NPT-1632S 1 2302076 !
T9001 or POWER TRANSFORMER NPT-1633S ( 1) 2302077 !
[CAPACITOR]
1
C4580 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K1 1 332121045R1
1
C6100 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-224J 1 374722244T
1
C6100 or FILM C C281H224J20A21A ( 1) 376822244T
1
C6101 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-224J 1 374722244T
1
C6101 or FILM C C281H224J20A21A ( 1) 376822244T
1
C6102 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-224J 1 374722244T
1
C6102 or FILM C C281H224J20A21A ( 1) 376822244T
1
C6103 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-224J 1 374722244T
1
C6103 or FILM C C281H224J20A21A ( 1) 376822244T
1
C6104 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-224J 1 374722244T
1
C6104 or FILM C C281H224J20A21A ( 1) 376822244T
1
C6105 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-224J 1 374722244T
1
C6105 or FILM C C281H224J20A21A ( 1) 376822244T
1
C6106 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-224J 1 374722244T
1
C6106 or FILM C C281H224J20A21A ( 1) 376822244T
1
C6110 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6111 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6112 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6113 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6114 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6115 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6116 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-473J 1 374724734T
1
C6917 TF TYPE PLASTIC FILM CAPACITOR ECQ-V50V-104J 1 374721044T
1
C6917 or FILM C C281H104J20A21A ( 1) 376821044T
C9001 IS TYPE CAPACITOR LE104-MX-C3.5 1 3800049S !
