Onkyo TX-RZ800

9/60 PAGE
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D6600 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6600 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6601 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6601 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6602 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6602 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6603 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6603 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6604 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6604 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6605 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6605 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6606 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6606 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6607 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6607 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6704 ZENER DIODE DZ2J036M0L 1 224760360R2
1
D6704 or ZENER DIODE UDZS3.6B ( 1) 224550360R2
1
D6901 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6901 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6902 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6902 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6903 ZENER DIODE DZ2J036M0L 1 224760360R2
1
D6903 or ZENER DIODE UDZS3.6B ( 1) 224550360R2
1
D6923 ZENER DIODE DZ2J036M0L 1 224760360R2
1
D6923 or ZENER DIODE UDZS3.6B ( 1) 224550360R2
1
D6924 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6924 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D9203 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D9203 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D9204 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D9204 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
D9205 DIODE D3SBA60 1 22380272F
1
Q6600 TRANSISTOR KRC105S 1 2217290R2
1
Q6600 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6600 or TRANSISTOR DTC123JKA ( 1) 2216690R2
1
Q6601 TRANSISTOR KRC105S 1 2217290R2
1
Q6601 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6601 or TRANSISTOR DTC123JKA ( 1) 2216690R2
1
Q6602 TRANSISTOR KRC105S 1 2217290R2
1
Q6602 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6602 or TRANSISTOR DTC123JKA ( 1) 2216690R2
1
Q6603 TRANSISTOR KRC105S 1 2217290R2
1
Q6603 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6603 or TRANSISTOR DTC123JKA ( 1) 2216690R2
1
Q6604 TRANSISTOR KRC105S 1 2217290R2
1
Q6604 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6604 or TRANSISTOR DTC123JKA ( 1) 2216690R2
1
Q6605 TRANSISTOR KRC105S 1 2217290R2
1
Q6605 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q6605 or TRANSISTOR DTC123JKA ( 1) 2216690R2
1
Q6606 TRANSISTOR KRC105S 1 2217290R2
1
Q6903 TRANSISTOR 2SA1163-BL 1 2216756R2
1
Q6904 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6910 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6913 TRANSISTOR 2SA1163-BL 1 2216756R2
1
Q6952 TRANSISTOR KTA1504-Y 1 2216184R2
Q6953 TRANSISTOR 2SC3851-Y 1 2203384
1
Q6953A HEAT SINK RAD-141 1 27160472
1
Q6953B SCREW 3P+6FN(3BC) 1 82143006GR
1
Q6960 TRANSISTOR 2SC2712-GR 1 2213145R2
1
Q6961 TRANSISTOR 2SC2713-BL 1 2213136R2
Q9202 HYBRID IC 79M12HF(NJM79M12FA) 1 222790125JRC
Q9203 HYBRID IC 78M12HF(NJM78M12FA) 1 222780125JRC
1
Q9203A HEAT SINK (RAD-255) 1 27160647
1
Q9203B SCREW 3P+6FN(3BC) 2 82143006GR
[CAPACITOR]
C6600 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 1 397581007AT
C6601 UTSP TYPE ELECTROLYTIC CAPACITOR CE04W50V-10M(UTSP) 1 397581007AT
