Onkyo TX-RZ800

12/60 PAGE
RL6604 RELAY NRL-2P3A-DC12-148 1 25065598A
RL6605 RELAY NRL-2P3A-DC12-148 1 25065598A
RL6606 RELAY NRL-2P3A-DC12-148 1 25065598A
RL6607 RELAY NRL-2P3A-DC12-148 1 25065598A
U003 BACLA-1787-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D5000 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5000 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5001 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5001 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5002 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5002 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5003 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5003 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5004 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5004 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5005 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5005 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5006 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5006 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D9303 DIODE RL1N4003 1 22380260T
1
D9304 DIODE RL1N4003 1 22380260T
1
D9305 DIODE RL1N4003 1 22380260T
1
D9306 DIODE RL1N4003 1 22380260T
1
D9307 ZENER DIODE DZ2J220M0L 1 224762200R2
1
D9307 or ZENER DIODE UDZS22B ( 1) 224552200R2
1
D9308 ZENER DIODE DZ2J220M0L 1 224762200R2
1
D9308 or ZENER DIODE UDZS22B ( 1) 224552200R2
1
Q5000 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5001 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5002 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5003 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5004 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5005 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5006 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5010 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5011 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5012 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5013 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5014 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5015 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5016 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q5020 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q5021 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q5022 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q5023 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q5024 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q5025 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q5026 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q5030 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5031 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5032 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5033 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5034 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5035 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5036 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5040 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5041 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5042 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5043 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5044 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5045 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5046 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5050 TRANSISTOR INA6006AP1-T111 1 2217980R2
1
Q5051 TRANSISTOR INA6006AP1-T111 1 2217980R2
