ENGLISH
Connect the positive red wire to the positive (+) terminal of your battery
and the negative black wire to the negative (-) terminal of your battery.
A 15 amp switch is recommended and should be installed on the
positive red wire.
Use a 15 amp fuse protection on the positive red wire to protect the
pump.
STEP 3
CONNECT PUMP TO 12V BATTERY
Ft. (m) AWG (mm2)
0-30 (0-9) AWG14
30-50 (9-15) AWG12
50-65 (15-19) AWG10
NOTE: Connect using stranded wire with gauge size in relation to
distance or length as dened in the table below.
Black (-)
(-)
Red (+) (+)
Fuse
Switch
Battery
