VADOplex
Packing list
VADOplex applied parts by intended use
VADOplex accessories list
Depends on indication
Device description
Device description Front side
●
Display
D
●
Control panel
A
●
Power switch on/o
E
Device description Rear side
●
Right tube connector
B
●
Left tube connector
C
●
Transport handle and bed mounting
I
●
Ventilation slots
G
●
Information on error messages
H
●
Supply cable connection
J
●
Communication interface for technical personnel
F
Device initialisation
●
Insert the power cable plug into a socket.
1
Caution: Make sure that the power cable plug is easily accessible and that it can be
unplugged at any time.
●
Plug the connecting hoses into the corresponding outputs.
2
●
To switch on the device, press the power switch to I.
4
After the device is switched on, the power switch is lit up green. A welcome messages is
shown on the display.
6
A 5-second countdown follows (5-4-3-2-1-0), shown at the top left on the display.
(
7
, illustrated at 3 seconds)
The patient hours can be viewed in the line behind the little man:
.
The total operating hours of the VADOplex device are displayed underneath:
(
7
, Sample image with 0 patient hours and 626 total operating hours)
●
When is the device ready for operation? This screen indicates that the self-check is
complete and the device is ready for operation.
8
The rst time the device is used, the following factory default settings are congured:
Program 1: 130 mmHg pressure with a pressure pulse duration of 1 second.
8
An overview for putting the device into operation is found at the front of the instructions
for use.
16
A
Control panel description
K
Start/Stop button
L
Individual pressure adjustment -/
M
Mode button
No. Item Quantity Item Number
1 Tubes green (3m)
2 pcs.
VXSY-TUBE-01-1
2 Pad (depends on indication) piece/pairs see VADOplex accessories list
Foot Pads Item-Number
1 piece of Foot Pad, Size Medium (37-41), left VXFP-01-1-M-LI
1 piece of Foot Pad, Size Medium (37-41), right
VXFP-01-1-M-RE
1 piece of Foot Pad, Size Large (42-47), left VXFP-01-1-L-LI
1 piece of Foot Pad, Size Large (42-47), right VXFP-01-1-L-RE
1 pair of Foot Pads, Size Medium (37-41) VXFP-02-1-M
1 pair of Foot Pads, Size Large (42-47) VXFP-02-1-L
1 box with 5 pairs VADOplex Foot Pads, Size Medium (37-41) VXFP-05-1-M
1 box with 5 pairs VADOplex Foot Pads, Size Large (42-47) VXFP-05-1-L
Calf Pads Item-Number
1 pair of Calf Pads VXCD-06-2
1 package (10 pairs) of Calf Pads VXCD-06-2
Hand Pads Item-Number
1 piece of Hand Pad, left VXHP-04-1-LI
1 piece of Hand Pad, right VXHP-04-1-RE
Undercast Pads Item-Number
1 Foot Pad for VACOped/VACOped Diabetic VXCP-03-1
No. Item Quantity Item Number
1 Controller incl. Power-Wire
1 pcs.
VXSY-07-1
2 Tubes green (3m)
2 pcs.
VXSY-TUBE-01-1
3 User Manual
1 pcs.
WM-TEVX-21-1-1
4
Pad
(depends on indication)
piece/
pairs
see VADOplex
accessories list
5 Box for controller
1 pcs.
PM-VXBO-01-1
6
Safety packaging in foam for controller 1 pair PM-VXRS-01-1
Single patient use only:
The pads are to be used for one patient only and may neither
be used for several patients nor refurbished
