VADOplex
Information on potential electromagnetic interference and advice on how to
avoid or minimize such interference
Guidance and manufacturer’s declaration – electromagnetic emission
The model VADOplex is intended for use in the electromagnetic environment specied below.
The customer or the user of the model VADOplex should assure that it is used in such an environment.
Emissions test Compliance Electromagnetic
environment – guidance
RF emissions
CISPR 11
Group 1 The model VADOplex uses RF
energy only for its internal
function. Therefore, its RF
emissions are very low and are not
likely to cause any interference in
nearby electronic equipment.
RF emissions
CISPR 11
Class B The model VADOplex is suitable
for use in all establishments,
including domestic establishments
and those directly connected
to the public low-voltage power
supply network that supplies
buildings used for domestic
purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage uctuations/
icker emissions
IEC 61000-3-3
Not applicable
Recommended separation distances between portable and mobile RF communications equipment
and the model VADOplex
The model VADOplex is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The customer or the user of the model VADOplex can help prevent
electromagnetic interference by maintaining a minimum distance between portable and mobile RF
communications equipment (transmitters) and the model VADOplex as recommended below,
according to the maximum output power of the communications equipment.
Rated maximum output
power of
transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz
to 80 MHz
d = 1,2
80 MHz
to 800 MHz
d = 1,2
800 MHz
to 2,5 GHz
d = 2,3
0,01 0,12 0,12 0,23
0,1 0,38 0,38 0,73
1 1,2 1,2 2,3
10 3,8 3,8 7,3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in metres (m)
can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power
rating of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is aected by absorption and
reection from structures, objects and people.
Information on potential electromagnetic interference and advice on how to
avoid or minimize such interference
Guidance and manufacturer’s declaration – electromagnetic immunity
The model VADOplex is intended for use in the electromagnetic environment specied below. The customer
or the user of the model VADOplex should assure that it is used in such an environment. The device
complies with the requirements (electromagnetic immunity) listed in Section 8.9 of IEC 60601-1-2:2014.
Immunity test IEC60601-1-2 test
level
Compliance level Electromagnetic environment –
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
± 8 kV contact
± 2 kV, ± 4 kV,
± 8 kV, ± 15 kV air
± 8 kV contact
± 2 kV, ± 4 kV,
± 8 kV, ± 15 kV air
Floors should be wood,
concrete or ceramic tile. If oors
are covered with synthetic
material, the relative humidity
should be at least 30 %.
Power frequency
(50/60Hz) magnetic
eld
IEC 61000-4-8
30 A/m 30 A/m Power frequency magnetic
elds should be at levels
characteristic of a typical
location of a professional
healthcare facility environment
and Home healthcare
environment.
Radiated RF EM
elds: Proximity
elds from RF
wireless
communications
equipment
IEC 61000-4-3
IEC 60601-1-2:2014
table 9
IEC 60601-1-2:2014
table 9
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV
100 kHz Repetition
Frequency
±2 kV
100 kHz Repetition
Frequency
Mains power quality should be
that of a professional healthcare
facility environment and Home
healthcare environment.
Surge
IEC 61000-4-5
±1 kV dierential
mode
±2 kV common
mode
±1 kV dierential
mode
±2 kV common
mode
Mains power quality should be
that of a professional healthcare
facility environment and Home
healthcare environment.
