257Self-help, vehicle care
Picture no: 17275t.tif
Xenon headlamp system 3,
Adaptive Forward Lighting
system 3
Headlamps have separate systems for
dipped beam 1 (inner bulbs) and main
beam 2 (outer bulbs).
Dipped beam
Picture no: 17276t.tif
Main beam
1. Replace bulbs through the openings in
the wheel arches 3 253.
2. Remove headlamp protective cover.
Picture no: 17277t.tif
3. Rotate left bulb holder and disengage.
9 Warning
Dipped beam works with a very high
electrical voltage. Do not touch, risk of
injury. Have a workshop replace the
bulb.
