128 Vehicle care
Brake light (1)
Turn signal light (2)
Tail light (3)
Tail light/fog light (4)
7. Install seal on bulb holder
ensuring it is fitted correctly.
Install bulb holder in light housing
ensuring that it engages properly.
Tighten four retaining screws
using a screw driver.
8. Install reverse light bulb holder
and turn clockwise to tighten.
9. Engage connector plug.
10. Insert light housing in body,
ensuring proper positioning.
Tighten three retaining screws.
Side turn signal lights
Have bulbs replaced by a workshop.
Centre high-mounted
brake light
Have bulbs replaced by a workshop.
Number plate light
Tailgate
1. Insert screwdriver as indicated by
the arrows, press to the side and
release the bulb housing.
