51Seats, Interior
Picture no: 14316s.tif
Pull Travel Assistant upwards out of
recesses.
There is a carrying handle on the back to
facilitate transport.
It is not necessary to remove the Travel
Assistant if you wish to raise the centre
seat, however, the armrest must be pushed
forwards. Be careful of any items in the
Travel Assistant.
Picture no: 14178s.tif
Rear seats
Sliding outboard rear seats front-rear
The rear outboard seats can be
individually adjusted front-rear.
Pull handle under seat, move seat, release
handle and allow seat to engage.
When pushing the seats back, to prevent
damage make sure the backrests are not in
their furthest back position.
Picture no: 14179s.tif
Adjust backrest rake of rear outboard
seats
Grasp backrest, pull handle at outboard
side of seat and guide backrest, unloaded,
into the required position. Release handle
and allow backrest to engage.
The backrest rake can be set in three
positions.
