Opt Lasers PLH3D-XT-50 - Technical Specifications

Technical Specifications
Performance Parameter
PLH3D-XT-50
Laser Diode’s Optical Power
1
[W]
6
Optical Power Density
[kW/cm²]
2500
Resolution
[µm (DPI)]
50 (>500)
Wavelength
[nm]
445 ± 10
Maximum Power Consumption
[W]
30
Control Signal Input
[V]
Analog - 0-5 / 0-10
PWM - 0-5 / 0-10 / 0-24
Power Supply Voltage
[V]
12-24
Dimensions
[cm³ (inch³)]
4.0 x 5.5 x 14.0
(1.6 x 1.7 x 5.51)
Weight
[kg (lb)]
0.370
(0.816)
Fan Flow Rate
[m
3
/ h (CFM)]
43 (25)
Fan Noise
[dBA]
58
Operating (Ambient) Temperature Range
[°C (°F)]
0-45
(32-113)
Mounting Hole Pattern
4 Holes,
24 mm by 15 mm
(0.94 in. by 0.59 in.)
Mounting Hole Type
M3 x 0.5 x 4.5 mm
