Optelec compact mini - Front Side

Optelec Compact
mini
English Page 8
Front side
The following figure shows the front side of the Compact
mini
.
Mode / Magnification wheel
Mode Pressing the wheel allows you to select one of the five viewing modes.
Magnification Turning the wheel clockwise or counter clockwise allows you to change
the magnification.
Cord fixture
