OPTi 604/6848 - Step 2: Attaching Console Masts

a. Fix the Left/Right Console Mast (2 & 3) to the Base Frame (1) with 2 x 20mm Allen Bolt (57) , 2 x 8mm
Spring Washers (60) and 2 x
Ф
8 x R20mm Arc Washer (62).And with 2 x 55mm Allen Bolt (58), 2 x 8mm
Spring Washers (60), 2 x 8mm Washer (61) and 2 x M8 Aircraft Nut (59) on both sides.
Assembly Instructions
Step 2
58
57
60
8
62
60
57
62
60
61
61
60
58
59
59
2
1
3
